** SOLD **
Casemakers are based on a combination of in line flexo printing, rotary die cutting and folder gluer. They are used to transform corrugated board sheets into finished cases in 1 pass.
Ask more informations
about a similar one
- Machine Code
- CB-CM15
- Manufacturer
- MARTIN
- Modello
- MIDLINE 924 -4 COLORS
- Year
- 1988
- Overhaul/renovation
- 2013
- Nominal Width (mm)
- 2400
- Max sheet width (mm)
- 900
- Max sheet lenght (mm)
- 2400
- Gearless
- No
- Max board thickness (mm)
- 9mm
- Speed (box/hour)
- 18000
- Set up system
- rapid set
- Printer
- Yes
- Num of colours
- 4
- Inking system
- pump
- Rotary die cutter
- Yes
- Slotter unit
- yes
- Die cutting unit
- yes
- Folder gluer unit
- yes
- Glue points
- 2
- Counter ejector
- yes
- Note
- Year: 1988 ( revised in 2013) Minimum format: 600 x 400. Maximum size: 2400 x 900. Thickness of clichés: 3,2mm. Maximum speed: 18,000 passages. Machine in excellent condition and still in production. Available January 2017. Configuration 924: 4 colors Rapidset. 2 Applicators glue nozzle + Control presence and length Container Technics. Removable Rotary Cutter Print station 1 and 3 with chambered doctor blade, print station 2 and 4 with rubber cylinder. Machine revised in 2013. New MPC2 for adjustment of the machine. Introducer with rotary valve + new vacuum pump. New drive on the slotter group. New generation of box six axes (slotter). Belt the settings to the folder tabs on the fly (new PIP ). Various parts of mechanical and electrical parts to have a screen roller and a rubber cylinder and an introduction cylinder.
| Machine Code | CB-CM15 |
| Manufacturer | MARTIN |
| Modello | MIDLINE 924 -4 COLORS |
| Year | 1988 |
| Overhaul/renovation | 2013 |
| Nominal Width (mm) | 2400 |
| Max sheet width (mm) | 900 |
| Max sheet lenght (mm) | 2400 |
| Gearless | No |
| Max board thickness (mm) | 9mm |
| Speed (box/hour) | 18000 |
| Set up system | rapid set |
| Printer | Yes |
| Num of colours | 4 |
| Inking system | pump |
| Rotary die cutter | Yes |
| Slotter unit | yes |
| Die cutting unit | yes |
| Folder gluer unit | yes |
| Glue points | 2 |
| Counter ejector | yes |
| Note | Year: 1988 ( revised in 2013) Minimum format: 600 x 400. Maximum size: 2400 x 900. Thickness of clichés: 3,2mm. Maximum speed: 18,000 passages. Machine in excellent condition and still in production. Available January 2017. Configuration 924: 4 colors Rapidset. 2 Applicators glue nozzle + Control presence and length Container Technics. Removable Rotary Cutter Print station 1 and 3 with chambered doctor blade, print station 2 and 4 with rubber cylinder. Machine revised in 2013. New MPC2 for adjustment of the machine. Introducer with rotary valve + new vacuum pump. New drive on the slotter group. New generation of box six axes (slotter). Belt the settings to the folder tabs on the fly (new PIP ). Various parts of mechanical and electrical parts to have a screen roller and a rubber cylinder and an introduction cylinder. |
