** SOLD **
A Vacuum metallizer is used to coat a layer of aluminium (or other metals) onto a web, typically plastic film or paper.
Ask more informations
about a similar one
- Machine Code
- ME43
- Manufacturer
- GALILEO
- Modello
- VACUUM MEGA 2410A
- Year
- 2000
- Overhaul/renovation
- Machine was recently renovated in Controlls. Recently retrofitted FALCON system
- Working width (mm)
- 2400
- Materials
- PET : 9-60mic,OPP : 15-100mic,PVC : 20-80mic,HDPE : 20-100mic,CPP : 20-80mic,PAPER
- Speed
- 840m/min
- Max diameter reel unwinder
- 1000mm
- Max diameter reel rewinder
- 1000mm
- Evapouration Boots
- Evaporator drivers – new gas system
- Pumping system
- -Pumping zone : Pumps in metallization chamber zone : 3pcs, diffusion pumps : 50000 l/s, 1pcs, mechanical roots pump : 5500 m3/h, Criogenic panel (Polycold) : 200.000l/s, 2pcs, mechanical pumps : 505m3/h, Pumps in winding chamber zone : 2pcs, mechanical roots pums : 13000 m3/h, 1pcs, mechanical roots pump : 5500 m3/h, Criogenic panel (Polycold ) : 200.000l/s, 2pcs, mechanical pumps : 505m3/h, Pumps in separation chamber zone : 1pcs, mechanical roots pump : 5500 m3/h, 1pcs, mechanical roots pump : 1000 m3/h,
- Plasma treatment
- Yes, Huttinger
- Polycold
- Yes
- Note
- PLC : SIEMENS S7 Loading & unloading automatic system Evaporator zone -Evaporation material : Al, Purity : 99,8%, Al wire diameter : 1,6mm, Evaporator number : 27, Evaporator size : 120x35x10 mm, Max. Al quantity on each evaporator : 10gr/min, Winding zone : Tension range : 3,5 – 90kg, Acceleration and Slow down : 30-60s, Machine dimension : Width : 8m, Length with open chambers : 18,5m, Max. high : 3,6m,
Machine Code | ME43 |
Manufacturer | GALILEO |
Modello | VACUUM MEGA 2410A |
Year | 2000 |
Overhaul/renovation | Machine was recently renovated in Controlls. Recently retrofitted FALCON system |
Working width (mm) | 2400 |
Materials | PET : 9-60mic,OPP : 15-100mic,PVC : 20-80mic,HDPE : 20-100mic,CPP : 20-80mic,PAPER |
Speed | 840m/min |
Max diameter reel unwinder | 1000mm |
Max diameter reel rewinder | 1000mm |
Evapouration Boots | Evaporator drivers – new gas system |
Pumping system | -Pumping zone : Pumps in metallization chamber zone : 3pcs, diffusion pumps : 50000 l/s, 1pcs, mechanical roots pump : 5500 m3/h, Criogenic panel (Polycold) : 200.000l/s, 2pcs, mechanical pumps : 505m3/h, Pumps in winding chamber zone : 2pcs, mechanical roots pums : 13000 m3/h, 1pcs, mechanical roots pump : 5500 m3/h, Criogenic panel (Polycold ) : 200.000l/s, 2pcs, mechanical pumps : 505m3/h, Pumps in separation chamber zone : 1pcs, mechanical roots pump : 5500 m3/h, 1pcs, mechanical roots pump : 1000 m3/h, |
Plasma treatment | Yes, Huttinger |
Polycold | Yes |
Note | PLC : SIEMENS S7 Loading & unloading automatic system Evaporator zone -Evaporation material : Al, Purity : 99,8%, Al wire diameter : 1,6mm, Evaporator number : 27, Evaporator size : 120x35x10 mm, Max. Al quantity on each evaporator : 10gr/min, Winding zone : Tension range : 3,5 – 90kg, Acceleration and Slow down : 30-60s, Machine dimension : Width : 8m, Length with open chambers : 18,5m, Max. high : 3,6m, |
