Coatings used in packaging industry are various. Cold and hot seal coating are common. Also, cold and hot seal coatings are commonly used, as well as hot melt and wax coatings. Silicon, Pvdc coating, ant mist and many others are employed. Materials which can be coated with a certain machine depends highly on the type of coating unit(s) available, on machine's construction and equipment.
Ask more informations
- Machine Code
- LA502
- Manufacturer
- NORDMECCANICA
- Modello
- Super Simplex 1500
- Year
- 2014
- Application
- Duplex lamination
- Type of lamination/coating
- SOLVENTLESS
- Working width (mm)
- 1500
- Materials
- BOPP, PET, CPP, Al foil, LDPE , paper up to 120 gsm
- Speed
- 450 mpm
- First unwinder type
- SINGLE POSITION SHAFTLESS
- Max diameter reel unwinder
- 1000
- Secondary unwinder type
- SINGLE POSITION SHAFTLESS
- Max diameter reel unwinder
- 1000
- Rewinder type
- SINGLE POSITION SHAFTLESS AC motor driven
- Max diameter reel rewinder
- 1000
- Coating unit
- 4 rolls type solventless
- pumping mixing unit
- Yes
- Corona treatment
- Yes, Enercon
- Note
- • Auto Adhesive tank filling • 40” Roll OD • Dancer assemblies on unwinds and rewinds • Edge guides on unwinds and rewinds • Temperature control units • Fume extraction blowers • Ozone extraction blowers
| Machine Code | LA502 |
| Manufacturer | NORDMECCANICA |
| Modello | Super Simplex 1500 |
| Year | 2014 |
| Application | Duplex lamination |
| Type of lamination/coating | SOLVENTLESS |
| Working width (mm) | 1500 |
| Materials | BOPP, PET, CPP, Al foil, LDPE , paper up to 120 gsm |
| Speed | 450 mpm |
| First unwinder type | SINGLE POSITION SHAFTLESS |
| Max diameter reel unwinder | 1000 |
| Secondary unwinder type | SINGLE POSITION SHAFTLESS |
| Max diameter reel unwinder | 1000 |
| Rewinder type | SINGLE POSITION SHAFTLESS AC motor driven |
| Max diameter reel rewinder | 1000 |
| Coating unit | 4 rolls type solventless |
| pumping mixing unit | Yes |
| Corona treatment | Yes, Enercon |
| Note | • Auto Adhesive tank filling • 40” Roll OD • Dancer assemblies on unwinds and rewinds • Edge guides on unwinds and rewinds • Temperature control units • Fume extraction blowers • Ozone extraction blowers |
