** SOLD **
In a blown film extruder PE granulates (or other polymer) are melted in an extruder and pushed through a circular die extruding a tube of molten polymer. Tube is then inflated to multiples of its initial diameter and cooled to form a thin film. Bobble is later collapsed and re-winded.
Ask more informations
about a similar one
- Machine Code
- EX625
- Manufacturer
- MACCHI
- Year
- 2006
- Number of layers
- 5
- Material
- LDPE, LLDPE, mLLDPE, HDPE, MDPE, blends, from 20 to 200 micron
- Film Width
- 2400
- Screw diam 1
- 55-65-80-65-55
- Head description
- IBC
- Die diam (mm)
- 500 with 2.2mm gap
- Thickness controll system
- Yes, Kunding K-100
- Bubble cage
- Yes
- Take off unit
- Oscillating
- Corona treatment
- AFS, type AVB-120D-SGM6/2400
- Web guide
- E+L web guide system FX5100
- Rewinder Type
- Double back to back
- Rewinder max reel diameter
- 1000 mm
- Note
- Tower construction included Included: K Design vari-cool profile control, 48 segments Spare parts: brand new screws and barrels for all extruders
| Machine Code | EX625 |
| Manufacturer | MACCHI |
| Year | 2006 |
| Number of layers | 5 |
| Material | LDPE, LLDPE, mLLDPE, HDPE, MDPE, blends, from 20 to 200 micron |
| Film Width | 2400 |
| Screw diam 1 | 55-65-80-65-55 |
| Head description | IBC |
| Die diam (mm) | 500 with 2.2mm gap |
| Thickness controll system | Yes, Kunding K-100 |
| Bubble cage | Yes |
| Take off unit | Oscillating |
| Corona treatment | AFS, type AVB-120D-SGM6/2400 |
| Web guide | E+L web guide system FX5100 |
| Rewinder Type | Double back to back |
| Rewinder max reel diameter | 1000 mm |
| Note | Tower construction included Included: K Design vari-cool profile control, 48 segments Spare parts: brand new screws and barrels for all extruders |
