Flexographic printing machines (often abbreviated as flexo press) perform a printing process which utilizes a flexible relief plate to transfer ink to printed substrate. Every printing job will require its dedicated set of plates.
Ask more informations
- Machine Code
- FL1080
- Manufacturer
- UTECO
- Modello
- ONYX 808 GL 130
- Year
- 2014
- Number of colors
- 8
- Print possibilityes
- 8+0
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1350
- Print width (mm)
- 1300
- Min print repeat (mm)
- 330
- Max print repeat (mm)
- 800
- Unwinder type
- Automatic turret
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Automatic turret
- Max reel diameter rewinder (mm)
- 1000
- Drying
- 2 Drying zones, 4 fans, 5 mt final tunnel , 2 Gas burners , automatic air recirculation with LEL
- Videocamera
- Yes Grafikontrol with defect control. 3 chip camera + 100% inspection
- Web guides
- Yes
- Vyscosity control
- Yes GAMA
- Washing system
- Auto clean
- Inking system
- Solvent-water based
- Anilox
- 12 ceramic anilox sleeves
- Print Sleeves
- to be confirmed
| Machine Code | FL1080 |
| Manufacturer | UTECO |
| Modello | ONYX 808 GL 130 |
| Year | 2014 |
| Number of colors | 8 |
| Print possibilityes | 8+0 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1350 |
| Print width (mm) | 1300 |
| Min print repeat (mm) | 330 |
| Max print repeat (mm) | 800 |
| Unwinder type | Automatic turret |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | Automatic turret |
| Max reel diameter rewinder (mm) | 1000 |
| Drying | 2 Drying zones, 4 fans, 5 mt final tunnel , 2 Gas burners , automatic air recirculation with LEL |
| Videocamera | Yes Grafikontrol with defect control. 3 chip camera + 100% inspection |
| Web guides | Yes |
| Vyscosity control | Yes GAMA |
| Washing system | Auto clean |
| Inking system | Solvent-water based |
| Anilox | 12 ceramic anilox sleeves |
| Print Sleeves | to be confirmed |
