UTECO EMERALD 825 GL 8+1 Flexo central drum printing press 9 colors

UTECO EMERALD 825  GL 8+1 Flexo central drum printing press 9 colors
** SOLD **

Flexographic printing machines (often abbreviated as flexo press) perform a printing process which utilizes a flexible relief plate to transfer ink to printed substrate. Every printing job will require its dedicated set of plates.

Ask more informations
about a similar one
Machine Code
FL796
Manufacturer
UTECO
Model
EMERALD 825 GL 8+1
Year
2001
Number of colors
9
Print possibilityes
8 (front) flexo + 1 (front) roto ; 1 (front) flexo + 1(back) roto
Gearless
Yes
Fast sleeve change
Yes
4 motor per deck CNC position system
Yes
Computer supervision
Yes
Web width (mm)
1250
Print width (mm)
1200
Min print repeat (mm)
330
Max print repeat (mm)
700
Unwinder type
Turret semi automatic
Max reel diameter unwinder (mm)
800
Rewinder type
Turret automatic
Max reel diameter rewinder (mm)
800
Drying
Thermal oil
Videocamera
No
Corona treatment
Vetapone
Web guides
FIFE
Vyscosity control
No
Washing system
No
Inking system
8 doctor blades ; 8 ink pumps
Anilox
1x4.5\400 ;3x5.5\340,6x5.5\300,1x4.7\315,1x4.4\400,1x7\280,1x5\280,1x5\290 ,1x7.5\160,1x8.5\110,1x7\160,2x12\160,3x12\120,1x10\140, 1x10\80 ,1x12\80, 1x20\80
Print Sleeves
8x350,8x360,8x370,8x374,8x380,8x390,13x400,8x410,8x415,8x420,13x430 ,8x440,18x450,7x460,8x465,8x470,13x480,8x490,9x510,8x520,7x521,8x525, 8x530,11x540,8v550,8x566,8x570,8x582,8x590,8x610,8x630,8x650,8x660
Additional information
Number of colors:8 flexo + 1 gravure. Thickness of printing plates and of adhesive for the plate:1.14 + 0.55 Control tension type:Dancer Speed 300m/min Materials: Bopp/OPP/PP 15-50my; PET 15-25my; LDPE 40-150my;paper 30-120 gr/m2; Alu foil 29-40my Thermostat for CI 19m lenght - 5.23 Height Installed power 220 kw Preregister Length register controlled by PLC Pre- register system Refrigerating unit for cooling cylinder Driven Infeed calender with tension control
Machine Code FL796
Manufacturer UTECO
Model EMERALD 825 GL 8+1
Year 2001
Number of colors 9
Print possibilityes 8 (front) flexo + 1 (front) roto ; 1 (front) flexo + 1(back) roto
Gearless Yes
Fast sleeve change Yes
4 motor per deck CNC position system Yes
Computer supervision Yes
Web width (mm) 1250
Print width (mm) 1200
Min print repeat (mm) 330
Max print repeat (mm) 700
Unwinder type Turret semi automatic
Max reel diameter unwinder (mm) 800
Rewinder type Turret automatic
Max reel diameter rewinder (mm) 800
Drying Thermal oil
Videocamera No
Corona treatment Vetapone
Web guides FIFE
Vyscosity control No
Washing system No
Inking system 8 doctor blades ; 8 ink pumps
Anilox 1x4.5\400 ;3x5.5\340,6x5.5\300,1x4.7\315,1x4.4\400,1x7\280,1x5\280,1x5\290 ,1x7.5\160,1x8.5\110,1x7\160,2x12\160,3x12\120,1x10\140, 1x10\80 ,1x12\80, 1x20\80
Print Sleeves 8x350,8x360,8x370,8x374,8x380,8x390,13x400,8x410,8x415,8x420,13x430 ,8x440,18x450,7x460,8x465,8x470,13x480,8x490,9x510,8x520,7x521,8x525, 8x530,11x540,8v550,8x566,8x570,8x582,8x590,8x610,8x630,8x650,8x660
Additional information Number of colors:8 flexo + 1 gravure. Thickness of printing plates and of adhesive for the plate:1.14 + 0.55 Control tension type:Dancer Speed 300m/min Materials: Bopp/OPP/PP 15-50my; PET 15-25my; LDPE 40-150my;paper 30-120 gr/m2; Alu foil 29-40my Thermostat for CI 19m lenght - 5.23 Height Installed power 220 kw Preregister Length register controlled by PLC Pre- register system Refrigerating unit for cooling cylinder Driven Infeed calender with tension control
