** SOLD **
Some sheeters may be capable to cut more layers of web in one passage. Others may be equipped to cut sheets in register with a pre-printed material.
Ask more informations
about a similar one
- Machine Code
- SS52
- Manufacturer
- CMG
- Modello
- TC II 1600
- Year
- 2004
- Type
- SYNCHRO
- Width (mm)
- 1600
- Sheet length
- 450-1550mm
- Materials
- Paper, board and laminates 100-600 gsm
- Note
- Double Unwind Board/paper material Max Diameter Reel in 1800 (mm) Core size 300 (mm) standard or 150 (mm) Web guidE FIfe Breaker installation with automatic adjustable setting Slittingm achine direction (sides-mid) – 3 knives Tidland Cotta Rotary knive system - Dust removal system (vacuum clean), anti static bar Cutting transversal: - Twin rotary cutting system - Dust removal system (vacuum clean), anti static bar Pallettizing - maximum height 1650 (mm) Speed: 250/min
| Machine Code | SS52 |
| Manufacturer | CMG |
| Modello | TC II 1600 |
| Year | 2004 |
| Type | SYNCHRO |
| Width (mm) | 1600 |
| Sheet length | 450-1550mm |
| Materials | Paper, board and laminates 100-600 gsm |
| Note | Double Unwind Board/paper material Max Diameter Reel in 1800 (mm) Core size 300 (mm) standard or 150 (mm) Web guidE FIfe Breaker installation with automatic adjustable setting Slittingm achine direction (sides-mid) – 3 knives Tidland Cotta Rotary knive system - Dust removal system (vacuum clean), anti static bar Cutting transversal: - Twin rotary cutting system - Dust removal system (vacuum clean), anti static bar Pallettizing - maximum height 1650 (mm) Speed: 250/min |
