** SOLD **
Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".
Ask more informations
about a similar one
- Machine Code
- FL858
- Manufacturer
- COMEXI
- Modello
- FJ 2108
- Year
- 2004
- Number of colors
- 8
- Print possibilityes
- 8+0
- Gearless
- No
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1270
- Print width (mm)
- 1220
- Min print repeat (mm)
- 350
- Max print repeat (mm)
- 800
- Unwinder type
- Turret Automatic
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Turret automatic
- Max reel diameter rewinder (mm)
- 800
- Drying
- 2 zones ,4 fans , 2 gas burners
- Videocamera
- Yes AVT Print Jupiter
- Web guides
- Yes in and out
- Vyscosity control
- Yes
- Inking system
- Closed chamber Doctor blades , 8 ink pumps
- Anilox
- 5 x280 L/cm , 2×220 L , 2×160 L, 2×140 L ; 1×80 L
- Print Sleeves
- Sleeves and gears :8 x370,380,400,420,440,460,500,6OO,620 mm ;6 x 635,650,670 mm ; 4 x 480 mm
- Note
- Paper : 20 – 125 gr LDPE : 25 – 150 µ OPP : 12 – 40 µ PET : 12 – 30 µ/ Motorized longitudinal register Motorized side register Four motor deck positioning
| Machine Code | FL858 |
| Manufacturer | COMEXI |
| Modello | FJ 2108 |
| Year | 2004 |
| Number of colors | 8 |
| Print possibilityes | 8+0 |
| Gearless | No |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1270 |
| Print width (mm) | 1220 |
| Min print repeat (mm) | 350 |
| Max print repeat (mm) | 800 |
| Unwinder type | Turret Automatic |
| Max reel diameter unwinder (mm) | 800 |
| Rewinder type | Turret automatic |
| Max reel diameter rewinder (mm) | 800 |
| Drying | 2 zones ,4 fans , 2 gas burners |
| Videocamera | Yes AVT Print Jupiter |
| Web guides | Yes in and out |
| Vyscosity control | Yes |
| Inking system | Closed chamber Doctor blades , 8 ink pumps |
| Anilox | 5 x280 L/cm , 2×220 L , 2×160 L, 2×140 L ; 1×80 L |
| Print Sleeves | Sleeves and gears :8 x370,380,400,420,440,460,500,6OO,620 mm ;6 x 635,650,670 mm ; 4 x 480 mm |
| Note | Paper : 20 – 125 gr LDPE : 25 – 150 µ OPP : 12 – 40 µ PET : 12 – 30 µ/ Motorized longitudinal register Motorized side register Four motor deck positioning |
