- Código Máquina
- FL858
- Constructor
- COMEXI
- Modello
- FJ 2108
- Año
- 2004
- Number of colors
- 8
- Print possibilityes
- 8+0
- Gearless
- No
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1270
- Print width (mm)
- 1220
- Min print repeat (mm)
- 350
- Max print repeat (mm)
- 800
- Unwinder type
- Turret Automatic
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Turret automatic
- Max reel diameter rewinder (mm)
- 800
- Drying
- 2 zones ,4 fans , 2 gas burners
- Videocamera
- Yes AVT Print Jupiter
- Web guides
- Yes in and out
- Vyscosity control
- Yes
- Inking system
- Closed chamber Doctor blades , 8 ink pumps
- Anilox
- 5 x280 L/cm , 2×220 L , 2×160 L, 2×140 L ; 1×80 L
- Print Sleeves
- Sleeves and gears :8 x370,380,400,420,440,460,500,6OO,620 mm ;6 x 635,650,670 mm ; 4 x 480 mm
- Note
- Paper : 20 – 125 gr LDPE : 25 – 150 µ OPP : 12 – 40 µ PET : 12 – 30 µ/ Motorized longitudinal register Motorized side register Four motor deck positioning
| Código Máquina | FL858 |
| Constructor | COMEXI |
| Modello | FJ 2108 |
| Año | 2004 |
| Number of colors | 8 |
| Print possibilityes | 8+0 |
| Gearless | No |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1270 |
| Print width (mm) | 1220 |
| Min print repeat (mm) | 350 |
| Max print repeat (mm) | 800 |
| Unwinder type | Turret Automatic |
| Max reel diameter unwinder (mm) | 800 |
| Rewinder type | Turret automatic |
| Max reel diameter rewinder (mm) | 800 |
| Drying | 2 zones ,4 fans , 2 gas burners |
| Videocamera | Yes AVT Print Jupiter |
| Web guides | Yes in and out |
| Vyscosity control | Yes |
| Inking system | Closed chamber Doctor blades , 8 ink pumps |
| Anilox | 5 x280 L/cm , 2×220 L , 2×160 L, 2×140 L ; 1×80 L |
| Print Sleeves | Sleeves and gears :8 x370,380,400,420,440,460,500,6OO,620 mm ;6 x 635,650,670 mm ; 4 x 480 mm |
| Note | Paper : 20 – 125 gr LDPE : 25 – 150 µ OPP : 12 – 40 µ PET : 12 – 30 µ/ Motorized longitudinal register Motorized side register Four motor deck positioning |
