UTECO DIAMOND HP Flexo central drum printing press 8 colors ** SOLD ** Ask more informations about a similar one

Flexo presses are used to print on different supports: plastic films, paper and aluminium foil.

Machine Code FL820
Manufacturer UTECO
Model DIAMOND HP
Year 2006
Number of colors 8
Print possibilities 8+0
Gearless Yes
Fast sleeve change Yes
4 motor per deck CNC position system Yes
Computer supervision Yes
Web width (mm) 1050
Print width (mm) 1000
Min print repeat (mm) 350
Max print repeat (mm) 900
Unwinder type Turret Automatic
Max reel diameter unwinder (mm) 1000
Rewinder type Turret Automatic
Max reel diameter rewinder (mm) 1000
Drying 2 zones driers , 4 fans , 6 meter tunnel , 2 gas burners, automatic recirculation system
Videocamera BST Premius digital 3 chip, with auto register control , new 2010
Web guides yes in and out
Vyscosity control yes Fasnacht
Washing system yes auto wash up system for anilox and inking system
Inking system Closed chaber doctor blades
Anilox 26 ceramic as follows : 9 x 340 l/cm , 3 x 300, 3 x 280 , 2 x 200, 3 x 160, 1x 140, 2 x 120 , 3 x 100
Print Sleeves 200 as follows 8 of each following repeats 350, 360, 370 , 380 , 385 , 390, 400, 410 , 420, 430, 440, 450, 460, 470, 480, 500, 520, 530, 540, 560, 580, 600, 620, 630, 650, 660, 720
Additional information Highh speeed press 500 mpm

** SOLD **
