Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".
Ask more informations
- Machine Code
- FL0737
- Manufacturer
- WINDMÖLLER & HÖLSCHER
- Modello
- ASTRAFLEX
- Year
- 1999
- Number of colors
- 8
- Print possibilityes
- 8+0
- Gearless
- Yes
- Fast sleeve change
- No
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1620
- Print width (mm)
- 1570
- Min print repeat (mm)
- 400
- Max print repeat (mm)
- 1010
- Unwinder type
- Turret Automatic with roll loading system
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Turret Automatic with roll unloading system
- Max reel diameter rewinder (mm)
- 1000
- Drying
- Gas drying, inter colour dryers and overhead dryer 6 mt
- Videocamera
- Eltromat
- Web guides
- BST Web Stroboscope
- Vyscosity control
- Yes
- Inking system
- closed chamber doctor blades
- Anilox
- 24 ceramic anilox rollers
- Print cylinders
- 200
- Note
- Trolleys for porta lift system, for change over sleeeve change for print cylinders on the trolley Gearless direct drive on printing cylinders Material : LDPE , PP , PA 20-50µ , HDPE 12 - 100µ , Composities max. 150µ , Paper 30 - 120 gsm Speed : mechanical 365 m/min Necessary retrofit of 6 new chambers doctor blades. Price 95.000 Euro
| Machine Code | FL0737 |
| Manufacturer | WINDMÖLLER & HÖLSCHER |
| Modello | ASTRAFLEX |
| Year | 1999 |
| Number of colors | 8 |
| Print possibilityes | 8+0 |
| Gearless | Yes |
| Fast sleeve change | No |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1620 |
| Print width (mm) | 1570 |
| Min print repeat (mm) | 400 |
| Max print repeat (mm) | 1010 |
| Unwinder type | Turret Automatic with roll loading system |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | Turret Automatic with roll unloading system |
| Max reel diameter rewinder (mm) | 1000 |
| Drying | Gas drying, inter colour dryers and overhead dryer 6 mt |
| Videocamera | Eltromat |
| Web guides | BST Web Stroboscope |
| Vyscosity control | Yes |
| Inking system | closed chamber doctor blades |
| Anilox | 24 ceramic anilox rollers |
| Print cylinders | 200 |
| Note | Trolleys for porta lift system, for change over sleeeve change for print cylinders on the trolley Gearless direct drive on printing cylinders Material : LDPE , PP , PA 20-50µ , HDPE 12 - 100µ , Composities max. 150µ , Paper 30 - 120 gsm Speed : mechanical 365 m/min Necessary retrofit of 6 new chambers doctor blades. Price 95.000 Euro |
