** SOLD **
Flexographic printing machines (often abbreviated as flexo press) perform a printing process which utilizes a flexible relief plate to transfer ink to printed substrate. Every printing job will require its dedicated set of plates.
Ask more informations
about a similar one
- Machine Code
- FL891
- Manufacturer
- SCHIAVI
- Modello
- ALPHA
- Year
- 2002
- Number of colors
- 8
- Print possibilityes
- 8+0
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1250
- Print width (mm)
- 1200
- Min print repeat (mm)
- 330
- Max print repeat (mm)
- 650
- Unwinder type
- Turret
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Turret
- Max reel diameter rewinder (mm)
- 800
- Drying
- Gas
- Videocamera
- BST
- Corona treatment
- Yes
- Web guides
- Yes in and out BST
- Vyscosity control
- Manual
- Washing system
- No
- Inking system
- ceramic anilox + chamber doctor blade
- Anilox
- 4x240linee, 1x100, 1x260, 2x320, 1x120, 1x80. More pieces available for extraprice
- Print Sleeves
- 8x 530mm on 98,792mm mandre. More sets available for extra price.l
- Note
- Min film thicknes: 12 my Max mech.speed: 250 m/min Overall sizes: LxWxH 16x6x5 m
Machine Code | FL891 |
Manufacturer | SCHIAVI |
Modello | ALPHA |
Year | 2002 |
Number of colors | 8 |
Print possibilityes | 8+0 |
Gearless | Yes |
Fast sleeve change | Yes |
4 motor per deck CNC position system | Yes |
Computer supervision | Yes |
Web width (mm) | 1250 |
Print width (mm) | 1200 |
Min print repeat (mm) | 330 |
Max print repeat (mm) | 650 |
Unwinder type | Turret |
Max reel diameter unwinder (mm) | 800 |
Rewinder type | Turret |
Max reel diameter rewinder (mm) | 800 |
Drying | Gas |
Videocamera | BST |
Corona treatment | Yes |
Web guides | Yes in and out BST |
Vyscosity control | Manual |
Washing system | No |
Inking system | ceramic anilox + chamber doctor blade |
Anilox | 4x240linee, 1x100, 1x260, 2x320, 1x120, 1x80. More pieces available for extraprice |
Print Sleeves | 8x 530mm on 98,792mm mandre. More sets available for extra price.l |
Note | Min film thicknes: 12 my Max mech.speed: 250 m/min Overall sizes: LxWxH 16x6x5 m |
