SITEC SMA 600-1300 slitter rewinder

Machines may have different constructions depending on: the type of material, its dimensions and the key performances required.

Ask more informations
Machine Code
SR443
Manufacturer
SITEC
Modello
SMA 600-1300
Year
1999
Working width (mm)
1300
Materials
Film, laminates, paper alluminium
Unwinder type
Shaftless with automatic reel pick up
Max diameter reel unwinder
1200
Rewinder type
Double shaft center driven
Max diameter reel rewinder
600
Rewinder description
Complete automatic reel unloading and cores loading and position system. Entire change of reel, cutting, reel unloading, new cores position, gluing , re-start, happens totally automatic. Differencial shafts with friction/clutches, shpere type. pressure roller mounted on linear guides, independent pressure roller for each winding roll
Min slit width
30mm
Knives
rotary knives
Note
Machine currently dismantled 3 winding shafts 3 inch 3 winding shafts 6 inch speed 450 m/min Erhardt + Leimer Typ DO 0101, zum Verfolgen der Steuerlinie Hot melt unit for material and core glue Pushing device for reels - with extraction system for shafts. Automatic insertion and positioning of new cores and automatic repositioning of new shafts Unloading and weighing of finished reels
Machine Code SR443
Manufacturer SITEC
Modello SMA 600-1300
Year 1999
Working width (mm) 1300
Materials Film, laminates, paper alluminium
Unwinder type Shaftless with automatic reel pick up
Max diameter reel unwinder 1200
Rewinder type Double shaft center driven
Max diameter reel rewinder 600
Rewinder description Complete automatic reel unloading and cores loading and position system. Entire change of reel, cutting, reel unloading, new cores position, gluing , re-start, happens totally automatic. Differencial shafts with friction/clutches, shpere type. pressure roller mounted on linear guides, independent pressure roller for each winding roll
Min slit width 30mm
Knives rotary knives
Note Machine currently dismantled 3 winding shafts 3 inch 3 winding shafts 6 inch speed 450 m/min Erhardt + Leimer Typ DO 0101, zum Verfolgen der Steuerlinie Hot melt unit for material and core glue Pushing device for reels - with extraction system for shafts. Automatic insertion and positioning of new cores and automatic repositioning of new shafts Unloading and weighing of finished reels
