UTECO ONYX 810 GL flexo printing machine 8 colors

** SOLD **

Flexo CI presses use a central drum which is common to all colours as counter impression roll.

Ask more informations
about a similar one
Machine Code
FL764
Manufacturer
UTECO
Model
ONYX 810 GL
Year
2006
Number of colors
8
Print possibilityes
8+0
Overhaul/renovation
2011 - Grafikontrol camera with clik&drag; 2013, new chambers and new washing system
Gearless
Yes
Fast sleeve change
Yes
4 motor per deck CNC position system
Yes
Computer supervision
Yes
Web width (mm)
1250
Print width (mm)
1200
Min print repeat (mm)
400
Max print repeat (mm)
1100
Unwinder type
AUTOMATIC TURRET
Max reel diameter unwinder (mm)
800
Rewinder type
AUTOMATIC TURRET
Max reel diameter rewinder (mm)
800
Drying
2 zones ; 2 gas burners; 4 fans; Extended drying tunnel 6 mt long ; automatic air recirculation system with LEL control by Heck
Videocamera
AUTOMATIC PRINT SETTING CLICK&DRAG
Web guides
2 X EDGE GUIDE CONTROL
Vyscosity control
FASNACHT FKR-S4
Washing system
AUTOMATIC WASHING SYSTEM
Inking system
CLOSED CHAMBER DOCTOR BLADE NEW SYSTEM 2013 - PNEUMATIC INK PUMPS
Anilox
17 ceramic anilox sleeves 6x340 l/cm-vol.1,24 ; 2x340 l/cm-vol.1,3 ; 7x250 l/cm-vol.1,74 ;
Print Sleeves
199 as follows : 16 x400 mm ; 8x410mm ; 8x420mm ; 8x430mm ; 8x440mm ; 8x450mm ; 16x460mm ; 8x480mm ; 8x500mm ; 16x520mm ; 16x540mm ; 8x560mm ;8x600mm ; 7x630mm ;8x640mm ; 8x660mm ; 8x670mm ; 8x700 ; 8x720mm ; 8x760mm ; 8x860mm
Machine Code FL764
Manufacturer UTECO
Model ONYX 810 GL
Year 2006
Number of colors 8
Print possibilityes 8+0
Overhaul/renovation 2011 - Grafikontrol camera with clik&drag; 2013, new chambers and new washing system
Gearless Yes
Fast sleeve change Yes
4 motor per deck CNC position system Yes
Computer supervision Yes
Web width (mm) 1250
Print width (mm) 1200
Min print repeat (mm) 400
Max print repeat (mm) 1100
Unwinder type AUTOMATIC TURRET
Max reel diameter unwinder (mm) 800
Rewinder type AUTOMATIC TURRET
Max reel diameter rewinder (mm) 800
Drying 2 zones ; 2 gas burners; 4 fans; Extended drying tunnel 6 mt long ; automatic air recirculation system with LEL control by Heck
Videocamera AUTOMATIC PRINT SETTING CLICK&DRAG
Web guides 2 X EDGE GUIDE CONTROL
Vyscosity control FASNACHT FKR-S4
Washing system AUTOMATIC WASHING SYSTEM
Inking system CLOSED CHAMBER DOCTOR BLADE NEW SYSTEM 2013 - PNEUMATIC INK PUMPS
Anilox 17 ceramic anilox sleeves 6x340 l/cm-vol.1,24 ; 2x340 l/cm-vol.1,3 ; 7x250 l/cm-vol.1,74 ;
Print Sleeves 199 as follows : 16 x400 mm ; 8x410mm ; 8x420mm ; 8x430mm ; 8x440mm ; 8x450mm ; 16x460mm ; 8x480mm ; 8x500mm ; 16x520mm ; 16x540mm ; 8x560mm ;8x600mm ; 7x630mm ;8x640mm ; 8x660mm ; 8x670mm ; 8x700 ; 8x720mm ; 8x760mm ; 8x860mm
** SOLD **
