** SOLD **
Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".
Ask more informations
about a similar one
- Machine Code
- FL691
- Manufacturer
- COMEXI
- Modello
- FW1508
- Year
- 2008
- Number of colors
- 8
- Print possibilityes
- 8+0
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1270
- Print width (mm)
- 1220
- Min print repeat (mm)
- 350
- Max print repeat (mm)
- 800
- Unwinder type
- turret automatic
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- turret automatic
- Max reel diameter rewinder (mm)
- 800
- Drying
- 2 zones four fans , two gas burners
- Videocamera
- 1 AVT
- Web guides
- 1 before rewind, 1 before printing
- Vyscosity control
- yes automatic
- Washing system
- Automatic washing
- Inking system
- closed chamber doctor blades
- Anilox
- 17 (6x400 l/cm , 2x360, 1x320, 1x300, 2x280, 2x200, 2x160, 3x100)
- Print Sleeves
- 70
| Machine Code | FL691 |
| Manufacturer | COMEXI |
| Modello | FW1508 |
| Year | 2008 |
| Number of colors | 8 |
| Print possibilityes | 8+0 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1270 |
| Print width (mm) | 1220 |
| Min print repeat (mm) | 350 |
| Max print repeat (mm) | 800 |
| Unwinder type | turret automatic |
| Max reel diameter unwinder (mm) | 800 |
| Rewinder type | turret automatic |
| Max reel diameter rewinder (mm) | 800 |
| Drying | 2 zones four fans , two gas burners |
| Videocamera | 1 AVT |
| Web guides | 1 before rewind, 1 before printing |
| Vyscosity control | yes automatic |
| Washing system | Automatic washing |
| Inking system | closed chamber doctor blades |
| Anilox | 17 (6x400 l/cm , 2x360, 1x320, 1x300, 2x280, 2x200, 2x160, 3x100) |
| Print Sleeves | 70 |
