- Código Máquina
- CA273
- Constructor
- WINDMÖLLER & HÖLSCHER
- Modello
- FILMEX
- Año
- 2014
- Number of layers
- 3
- Film structure
- ABC
- Material
- CPP and CPE
- Film width (mm)
- 2400
- Speed (m/min)
- 350 m/ min mechanical
- Output (Kg/h)
- 1000kg/h depending on materials
- Extruder 1 Layer ref:
- A
- Screw diam 1
- 90mm L/D30,
- Description 1
- - output 350 kg/h - 3 comp gravimetric dosing Module G3 with vacuum feeders - max screw rpm 250 - AC motor 125 kW, inverter controlled - Heating 30kW, air cooled + water cooling for feeding section - Bimetallic barrel and anti wear lining of feed barrel in tungsten carbide - Hydraulic screen changer - Pro control TS supervision
- Extruder 2 Layer ref:
- B
- Screw diam 2
- 150mm L/D30
- Description 2
- - output 800 kg/h - 3 comp gravimetric dosing Module G3 with vacuum feeders - max screw rpm 165 - AC motor 370 kW - inverter controlled - Heating 75kW, air cooled + water cooling for feeding section - Bimetallic barrel and anti wear lining of feed barrel in tungsten carbide - Hydraulic screen changer - Pro control TS supervision
- Extruder 3 Layer ref:
- C
- Screw diam 3
- 90mm L/D30
- Description 3
- - output 155 kg/h - 3 comp gravimetric dosing Module G3 with vacuum feeders - max screw rpm 350 - AC motor 60 kW - inverter controlled - Heating 14,4kW, + water cooling for feeding section - Bimetallic barrel and anti wear lining of feed barrel in tungsten carbide - Hydraulic screen changer - Pro control TS supervision
- Note
- - Thicknesses 18-150 my - Edge trim and vacuum aspiration system width max 75mm
| Código Máquina | CA273 |
| Constructor | WINDMÖLLER & HÖLSCHER |
| Modello | FILMEX |
| Año | 2014 |
| Number of layers | 3 |
| Film structure | ABC |
| Material | CPP and CPE |
| Film width (mm) | 2400 |
| Speed (m/min) | 350 m/ min mechanical |
| Output (Kg/h) | 1000kg/h depending on materials |
| Extruder 1 Layer ref: | A |
| Screw diam 1 | 90mm L/D30, |
| Description 1 | - output 350 kg/h - 3 comp gravimetric dosing Module G3 with vacuum feeders - max screw rpm 250 - AC motor 125 kW, inverter controlled - Heating 30kW, air cooled + water cooling for feeding section - Bimetallic barrel and anti wear lining of feed barrel in tungsten carbide - Hydraulic screen changer - Pro control TS supervision |
| Extruder 2 Layer ref: | B |
| Screw diam 2 | 150mm L/D30 |
| Description 2 | - output 800 kg/h - 3 comp gravimetric dosing Module G3 with vacuum feeders - max screw rpm 165 - AC motor 370 kW - inverter controlled - Heating 75kW, air cooled + water cooling for feeding section - Bimetallic barrel and anti wear lining of feed barrel in tungsten carbide - Hydraulic screen changer - Pro control TS supervision |
| Extruder 3 Layer ref: | C |
| Screw diam 3 | 90mm L/D30 |
| Description 3 | - output 155 kg/h - 3 comp gravimetric dosing Module G3 with vacuum feeders - max screw rpm 350 - AC motor 60 kW - inverter controlled - Heating 14,4kW, + water cooling for feeding section - Bimetallic barrel and anti wear lining of feed barrel in tungsten carbide - Hydraulic screen changer - Pro control TS supervision |
| Note | - Thicknesses 18-150 my - Edge trim and vacuum aspiration system width max 75mm |
