MAKLAUS RES04 Unwinder / rewinder // Unwinder-Rewinder // Other machine // Used Flexo Press // Tecno Converting 2000 S.r.l.

Unwinders and rewinders are used as components in different types of machines, like printing machines, laminators, extrusion lines.

Photo Gallery

Machine Code: UN-RE42
Manufacturer: MAKLAUS
Modello: RES04
Year: 2007
Working width (mm): 500
Note: Machines are sold with capital overhaul. Duration of overhaul 60 days from order. Working speed 800m/min Rated Power: 5Kw Minimum Chuck Allowed: Internal Diameter 38Mm Maximum Spindle Allowed: Internal Diameter 72Mm Nominal Maximum Speed: 1000Mt/M Useful Main Coil Or Jumbo: 500Mm Band Main Or Jumbo Coil Diameter: 500Mm Maximum Weight Of Main Or Jumbo Reel: 50Kg Minimum Thickness: 7 Microns Maximum Thickness: 30 Microns Final Products: Manual Reels In Sizes From 1.8Kg To 2.4Kg Reel For Automatic Machines From 15Kg To 25Kg With 72Mm Internal Core And A Maximum Allowed Cardboard Core Thickness Of 10Mm

Machine Code	UN-RE42
Manufacturer	MAKLAUS
Modello	RES04
Year	2007
Working width (mm)	500
Note	Machines are sold with capital overhaul. Duration of overhaul 60 days from order. Working speed 800m/min Rated Power: 5Kw Minimum Chuck Allowed: Internal Diameter 38Mm Maximum Spindle Allowed: Internal Diameter 72Mm Nominal Maximum Speed: 1000Mt/M Useful Main Coil Or Jumbo: 500Mm Band Main Or Jumbo Coil Diameter: 500Mm Maximum Weight Of Main Or Jumbo Reel: 50Kg Minimum Thickness: 7 Microns Maximum Thickness: 30 Microns Final Products: Manual Reels In Sizes From 1.8Kg To 2.4Kg Reel For Automatic Machines From 15Kg To 25Kg With 72Mm Internal Core And A Maximum Allowed Cardboard Core Thickness Of 10Mm
