Lamination machines for flexible packaging industry are used to join together different webs creating a single web composed of a multi layer structure. Laminators coat a glue on a primary material and laminates secondary material onto it.
Ask more informations
- Machine Code
- LA159
- Manufacturer
- SIDECO
- Year
- 1999
- Application
- Coating
- Type of lamination/coating
- WATER BASED
- Working width (mm)
- 1650
- Speed
- 150mt/min
- First unwinder type
- TURRET AUTOMATIC
- Max diameter reel unwinder
- 800
- Rewinder type
- TURRET AUTOMATIC
- Max diameter reel rewinder
- 800
- Coating unit
- Mayer bar
- Drying
- Gas unit 600.000 Kcal/hr (included) ; 5 dryer section of 3m;
- pumping mixing unit
- No
- Corona treatment
- No
- Note
- Acrylic coating line for paper adhesive tapes, labels. Electrical power service 120 Kw (90 Kw) ; Core size at unwinder/rewinder : 152mm; Coating head mayer bar; Web guiding system; Cooling roll; Possibility to add as Option Secondary Unwinder for lamination and modification of chill roller nip
| Machine Code | LA159 |
| Manufacturer | SIDECO |
| Year | 1999 |
| Application | Coating |
| Type of lamination/coating | WATER BASED |
| Working width (mm) | 1650 |
| Speed | 150mt/min |
| First unwinder type | TURRET AUTOMATIC |
| Max diameter reel unwinder | 800 |
| Rewinder type | TURRET AUTOMATIC |
| Max diameter reel rewinder | 800 |
| Coating unit | Mayer bar |
| Drying | Gas unit 600.000 Kcal/hr (included) ; 5 dryer section of 3m; |
| pumping mixing unit | No |
| Corona treatment | No |
| Note | Acrylic coating line for paper adhesive tapes, labels. Electrical power service 120 Kw (90 Kw) ; Core size at unwinder/rewinder : 152mm; Coating head mayer bar; Web guiding system; Cooling roll; Possibility to add as Option Secondary Unwinder for lamination and modification of chill roller nip |
