FLEXOTECNICA 10 NG (GEARLESS) flexo printing machine 10 colors

** SOLD **

Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".

Ask more informations
about a similar one
Machine Code
FL546
Manufacturer
FLEXOTECNICA
Model
10 NG (GEARLESS)
Year
2009
Number of colors
10
Print possibilityes
10+0
Gearless
Yes
Fast sleeve change
Yes
4 motor per deck CNC position system
No
Computer supervision
Yes
Web width (mm)
1270
Print width (mm)
1220
Min print repeat (mm)
400
Max print repeat (mm)
900
Unwinder type
Turret Automatic
Max reel diameter unwinder (mm)
1000
Rewinder type
Turret Automatic
Max reel diameter rewinder (mm)
1000
Drying
2 drying zones - extended tnnel 6 mt, 4 fans ,2 gas burners , automatic recirculation system with LEL
Videocamera
AVT Jupiter with defekt control
Corona treatment
Ferrarini Benelli
Web guides
yes in and out
Vyscosity control
10 by Gama
Washing system
fully automatic
Inking system
close chamber doctor blades
Anilox
18 ceramic anilox sleeves
Print Sleeves
60 print sleeves OPTION ADDITIONAL 140
Additional information
Machine in excellent conditions as new .Fully equipped
Machine Code FL546
Manufacturer FLEXOTECNICA
Model 10 NG (GEARLESS)
Year 2009
Number of colors 10
Print possibilityes 10+0
Gearless Yes
Fast sleeve change Yes
4 motor per deck CNC position system No
Computer supervision Yes
Web width (mm) 1270
Print width (mm) 1220
Min print repeat (mm) 400
Max print repeat (mm) 900
Unwinder type Turret Automatic
Max reel diameter unwinder (mm) 1000
Rewinder type Turret Automatic
Max reel diameter rewinder (mm) 1000
Drying 2 drying zones - extended tnnel 6 mt, 4 fans ,2 gas burners , automatic recirculation system with LEL
Videocamera AVT Jupiter with defekt control
Corona treatment Ferrarini Benelli
Web guides yes in and out
Vyscosity control 10 by Gama
Washing system fully automatic
Inking system close chamber doctor blades
Anilox 18 ceramic anilox sleeves
Print Sleeves 60 print sleeves OPTION ADDITIONAL 140
Additional information Machine in excellent conditions as new .Fully equipped
