** SOLD **
Flexo presses are used to print on different supports: plastic films, paper and aluminium foil.
Ask more informations
about a similar one
- Machine Code
- FL1096
- Manufacturer
- UTECO
- Modello
- ONYX 110
- Year
- 2014
- Number of colors
- 10
- Print possibilityes
- 10+0
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1350
- Print width (mm)
- 1300
- Min print repeat (mm)
- 380
- Max print repeat (mm)
- 1100
- Unwinder type
- Turret Automatic with roll loading system
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Turret Automatic with roll unloading system
- Max reel diameter rewinder (mm)
- 1000
- Drying
- 2 zones , 4 fans , final tunnel 6 mt length , 2 Gas Burners 200.000 Kcl/h each, Automatic Air recirculation system with LEL controls on each zone Zellweger
- Videocamera
- BST Premius 3 chip , BST Q-Center automatic 100% inspection system
- Web guides
- Yes in and out
- Vyscosity control
- Yes automatic
- Washing system
- Yes automatic
- Inking system
- Closed chamber doctor blades - 10 Chamber + 4 spares
- Anilox
- 12 ceramic anilox sleeves
- Print Sleeves
- 30
- Print cylinders
- Print cylinder mandrels in Carbon fiber 114, 7 mm diam - 20 Carbon fiber carriers
- Note
- Complete automatic print setting and control with following features : -Register control by inspection system - Printing pressure setting and control Kiss&Go - Print defect control - Colour control -Bar code control
| Machine Code | FL1096 |
| Manufacturer | UTECO |
| Modello | ONYX 110 |
| Year | 2014 |
| Number of colors | 10 |
| Print possibilityes | 10+0 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1350 |
| Print width (mm) | 1300 |
| Min print repeat (mm) | 380 |
| Max print repeat (mm) | 1100 |
| Unwinder type | Turret Automatic with roll loading system |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | Turret Automatic with roll unloading system |
| Max reel diameter rewinder (mm) | 1000 |
| Drying | 2 zones , 4 fans , final tunnel 6 mt length , 2 Gas Burners 200.000 Kcl/h each, Automatic Air recirculation system with LEL controls on each zone Zellweger |
| Videocamera | BST Premius 3 chip , BST Q-Center automatic 100% inspection system |
| Web guides | Yes in and out |
| Vyscosity control | Yes automatic |
| Washing system | Yes automatic |
| Inking system | Closed chamber doctor blades - 10 Chamber + 4 spares |
| Anilox | 12 ceramic anilox sleeves |
| Print Sleeves | 30 |
| Print cylinders | Print cylinder mandrels in Carbon fiber 114, 7 mm diam - 20 Carbon fiber carriers |
| Note | Complete automatic print setting and control with following features : -Register control by inspection system - Printing pressure setting and control Kiss&Go - Print defect control - Colour control -Bar code control |
