** SOLD **
Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".
Ask more informations
about a similar one
- Machine Code
- FL994
- Manufacturer
- UTECO
- Modello
- Quarz 603
- Year
- 1994
- Number of colors
- 6
- Print possibilityes
- 6+0
- Gearless
- No
- Fast sleeve change
- No
- 4 motor per deck CNC position system
- No
- Computer supervision
- Yes
- Web width (mm)
- 1450
- Print width (mm)
- 1400
- Min print repeat (mm)
- 350
- Max print repeat (mm)
- 1000
- Unwinder type
- Semiautomatic turret drop Slice
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Automatic turret non stop
- Max reel diameter rewinder (mm)
- 800
- Drying
- 2 zones 4 fans 3mt tunnel , Heating by steam with heat exchangers
- Videocamera
- BST
- Anilox
- 20 ceramic anilox rolelrs between 60 l/cm and 320 l/cm
- Print cylinders
- 10 x each of following repeats 35 cm, 38 , 40 , 45, 50 ,60 ; 6 for each following repeats 52cm, 54 , 65, 70 , 4 x 55 cm, and 65 ,
| Machine Code | FL994 |
| Manufacturer | UTECO |
| Modello | Quarz 603 |
| Year | 1994 |
| Number of colors | 6 |
| Print possibilityes | 6+0 |
| Gearless | No |
| Fast sleeve change | No |
| 4 motor per deck CNC position system | No |
| Computer supervision | Yes |
| Web width (mm) | 1450 |
| Print width (mm) | 1400 |
| Min print repeat (mm) | 350 |
| Max print repeat (mm) | 1000 |
| Unwinder type | Semiautomatic turret drop Slice |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | Automatic turret non stop |
| Max reel diameter rewinder (mm) | 800 |
| Drying | 2 zones 4 fans 3mt tunnel , Heating by steam with heat exchangers |
| Videocamera | BST |
| Anilox | 20 ceramic anilox rolelrs between 60 l/cm and 320 l/cm |
| Print cylinders | 10 x each of following repeats 35 cm, 38 , 40 , 45, 50 ,60 ; 6 for each following repeats 52cm, 54 , 65, 70 , 4 x 55 cm, and 65 , |
