** SOLD **
Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".
Ask more informations
about a similar one
- Machine Code
- FL833
- Manufacturer
- WINDMÖLLER & HÖLSCHER
- Modello
- PRIMAFLEX CS
- Year
- 2005
- Number of colors
- 8
- Print possibilityes
- 8+0
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 850
- Print width (mm)
- 820
- Min print repeat (mm)
- 250
- Max print repeat (mm)
- 800
- Unwinder type
- Turret Automatic non-stop
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Turret Automatic non-stop
- Max reel diameter rewinder (mm)
- 800
- Drying
- Electric - Drying between colors and bridge dryer system
- Videocamera
- BST
- Corona treatment
- Corona AFS Treatment
- Web guides
- Before printing and after rewinding BST
- Washing system
- yes
- Inking system
- Water /solvent . Doctor Blade Chamber
- Anilox
- Approx. 16
- Print Sleeves
- Approx. 150
- Note
- Material to be printed PAPER / PE / LDPE / HDPE / PA / PP / OPP / BOPP / PET Length register : through gearless Side register : electric - Motorized 8 - Pneumatic PUMPS Length cutting with circular knifes
| Machine Code | FL833 |
| Manufacturer | WINDMÖLLER & HÖLSCHER |
| Modello | PRIMAFLEX CS |
| Year | 2005 |
| Number of colors | 8 |
| Print possibilityes | 8+0 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 850 |
| Print width (mm) | 820 |
| Min print repeat (mm) | 250 |
| Max print repeat (mm) | 800 |
| Unwinder type | Turret Automatic non-stop |
| Max reel diameter unwinder (mm) | 800 |
| Rewinder type | Turret Automatic non-stop |
| Max reel diameter rewinder (mm) | 800 |
| Drying | Electric - Drying between colors and bridge dryer system |
| Videocamera | BST |
| Corona treatment | Corona AFS Treatment |
| Web guides | Before printing and after rewinding BST |
| Washing system | yes |
| Inking system | Water /solvent . Doctor Blade Chamber |
| Anilox | Approx. 16 |
| Print Sleeves | Approx. 150 |
| Note | Material to be printed PAPER / PE / LDPE / HDPE / PA / PP / OPP / BOPP / PET Length register : through gearless Side register : electric - Motorized 8 - Pneumatic PUMPS Length cutting with circular knifes |
