** SOLD **
Flexographic printing machines (often abbreviated as flexo press) perform a printing process which utilizes a flexible relief plate to transfer ink to printed substrate. Every printing job will require its dedicated set of plates.
Ask more informations
about a similar one
- Machine Code
- FL855
- Manufacturer
- UTECO
- Modello
- ONYX 808
- Year
- 2010
- Number of colors
- 8
- Print possibilityes
- 8+0
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1350
- Print width (mm)
- 1300
- Min print repeat (mm)
- 350
- Max print repeat (mm)
- 800
- Unwinder type
- Turret Automatic
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Turret Automatic
- Max reel diameter rewinder (mm)
- 800
- Drying
- 2 zones , four fans , extended drying tunnel 4 mt , Two gas burners , Automatic recirculation system with LEL control
- Videocamera
- Video inspection system Grafikontrol with interactive register control Click&Drag
- Web guides
- Yes in and out
- Vyscosity control
- Viscosity controllers
- Washing system
- Semi Automatic washing system for doctor blades and aniloxes;
- Inking system
- Closed chamber doctor blades with quick changeover of the blades and side sealings and Double pneumatic inking pumps
- Anilox
- 12 ceramic anilox sleeves 3 x 900 L/inch, vol.2,3 BCM; 2 X 800 L/inch , vol 2,3 BCM ; 1 x 700L/inch ; 3 x 550L/inch vol. 5,5 ; 1x350 l/inch -vol .5,9 ; 2 x250L/inch -vol.9
- Print Sleeves
- 56 repeats 14.5” , 15” 16.25” , 17” , 17.5” , 18.25” , 19.25
- Note
- Gearless machine with patented Direct Drive Evo; Chiller;
| Machine Code | FL855 |
| Manufacturer | UTECO |
| Modello | ONYX 808 |
| Year | 2010 |
| Number of colors | 8 |
| Print possibilityes | 8+0 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1350 |
| Print width (mm) | 1300 |
| Min print repeat (mm) | 350 |
| Max print repeat (mm) | 800 |
| Unwinder type | Turret Automatic |
| Max reel diameter unwinder (mm) | 800 |
| Rewinder type | Turret Automatic |
| Max reel diameter rewinder (mm) | 800 |
| Drying | 2 zones , four fans , extended drying tunnel 4 mt , Two gas burners , Automatic recirculation system with LEL control |
| Videocamera | Video inspection system Grafikontrol with interactive register control Click&Drag |
| Web guides | Yes in and out |
| Vyscosity control | Viscosity controllers |
| Washing system | Semi Automatic washing system for doctor blades and aniloxes; |
| Inking system | Closed chamber doctor blades with quick changeover of the blades and side sealings and Double pneumatic inking pumps |
| Anilox | 12 ceramic anilox sleeves 3 x 900 L/inch, vol.2,3 BCM; 2 X 800 L/inch , vol 2,3 BCM ; 1 x 700L/inch ; 3 x 550L/inch vol. 5,5 ; 1x350 l/inch -vol .5,9 ; 2 x250L/inch -vol.9 |
| Print Sleeves | 56 repeats 14.5” , 15” 16.25” , 17” , 17.5” , 18.25” , 19.25 |
| Note | Gearless machine with patented Direct Drive Evo; Chiller; |
