- Codice Macchina
- FL855
- Manufacturer
- UTECO
- Modello
- ONYX 808
- Year
- 2010
- Numero di colori
- 8
- Print possibilityes
- 8+0
- Gearless
- Yes
- Cambio a maniche rapido
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Larghezza nastro (mm)
- 1350
- Larghezza stampa (mm)
- 1300
- Min print repeat (mm)
- 350
- Max print repeat (mm)
- 800
- Unwinder type
- Turret Automatic
- Diametro massimo svolgitore (mm)
- 800
- Rewinder type
- Turret Automatic
- Max reel diameter rewinder (mm)
- 800
- Essiccazione
- 2 zones , four fans , extended drying tunnel 4 mt , Two gas burners , Automatic recirculation system with LEL control
- Videocamera
- Video inspection system Grafikontrol with interactive register control Click&Drag
- Guida film
- Yes in and out
- Vyscosity control
- Viscosity controllers
- Washing system
- Semi Automatic washing system for doctor blades and aniloxes;
- Sistema d'inchiostro
- Closed chamber doctor blades with quick changeover of the blades and side sealings and Double pneumatic inking pumps
- Anilox
- 12 ceramic anilox sleeves 3 x 900 L/inch, vol.2,3 BCM; 2 X 800 L/inch , vol 2,3 BCM ; 1 x 700L/inch ; 3 x 550L/inch vol. 5,5 ; 1x350 l/inch -vol .5,9 ; 2 x250L/inch -vol.9
- Maniche stampa
- 56 repeats 14.5” , 15” 16.25” , 17” , 17.5” , 18.25” , 19.25
- Ulteriori informazioni
- Gearless machine with patented Direct Drive Evo; Chiller;
| Codice Macchina | FL855 |
| Manufacturer | UTECO |
| Modello | ONYX 808 |
| Year | 2010 |
| Numero di colori | 8 |
| Print possibilityes | 8+0 |
| Gearless | Yes |
| Cambio a maniche rapido | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Larghezza nastro (mm) | 1350 |
| Larghezza stampa (mm) | 1300 |
| Min print repeat (mm) | 350 |
| Max print repeat (mm) | 800 |
| Unwinder type | Turret Automatic |
| Diametro massimo svolgitore (mm) | 800 |
| Rewinder type | Turret Automatic |
| Max reel diameter rewinder (mm) | 800 |
| Essiccazione | 2 zones , four fans , extended drying tunnel 4 mt , Two gas burners , Automatic recirculation system with LEL control |
| Videocamera | Video inspection system Grafikontrol with interactive register control Click&Drag |
| Guida film | Yes in and out |
| Vyscosity control | Viscosity controllers |
| Washing system | Semi Automatic washing system for doctor blades and aniloxes; |
| Sistema d'inchiostro | Closed chamber doctor blades with quick changeover of the blades and side sealings and Double pneumatic inking pumps |
| Anilox | 12 ceramic anilox sleeves 3 x 900 L/inch, vol.2,3 BCM; 2 X 800 L/inch , vol 2,3 BCM ; 1 x 700L/inch ; 3 x 550L/inch vol. 5,5 ; 1x350 l/inch -vol .5,9 ; 2 x250L/inch -vol.9 |
| Maniche stampa | 56 repeats 14.5” , 15” 16.25” , 17” , 17.5” , 18.25” , 19.25 |
| Ulteriori informazioni | Gearless machine with patented Direct Drive Evo; Chiller; |
