** SOLD **
Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".
Ask more informations
about a similar one
- Machine Code
- FL816
- Manufacturer
- NOVAGRAF
- Modello
- FL 40 7C
- Year
- 2008
- Number of colors
- 8
- Gearless
- No
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1350
- Print width (mm)
- 1300
- Min print repeat (mm)
- 380
- Max print repeat (mm)
- 750
- Unwinder type
- Turret
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Non- stop rewinder
- Max reel diameter rewinder (mm)
- 800
- Drying
- electric
- Videocamera
- AVT Video system
- Corona treatment
- yes
- Web guides
- yes
- Vyscosity control
- yes
- Inking system
- Water base inks
- Anilox
- 14 Anilox
- Print Sleeves
- Some sets of sleeves available
- Note
- Speed 350 mpm Material: paper from 80 to 140 gr/m2 Plate thickness: 1,14 mm+ 0,5 adhesive Gear-Pitch Module: 5 mm
Machine Code | FL816 |
Manufacturer | NOVAGRAF |
Modello | FL 40 7C |
Year | 2008 |
Number of colors | 8 |
Gearless | No |
Fast sleeve change | Yes |
4 motor per deck CNC position system | Yes |
Computer supervision | Yes |
Web width (mm) | 1350 |
Print width (mm) | 1300 |
Min print repeat (mm) | 380 |
Max print repeat (mm) | 750 |
Unwinder type | Turret |
Max reel diameter unwinder (mm) | 800 |
Rewinder type | Non- stop rewinder |
Max reel diameter rewinder (mm) | 800 |
Drying | electric |
Videocamera | AVT Video system |
Corona treatment | yes |
Web guides | yes |
Vyscosity control | yes |
Inking system | Water base inks |
Anilox | 14 Anilox |
Print Sleeves | Some sets of sleeves available |
Note | Speed 350 mpm Material: paper from 80 to 140 gr/m2 Plate thickness: 1,14 mm+ 0,5 adhesive Gear-Pitch Module: 5 mm |
