** SOLD **
Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".
Ask more informations
about a similar one
- Machine Code
- FL773
- Manufacturer
- OFEM
- Modello
- JULIETTE 758
- Year
- 2000
- Number of colors
- 8
- Print possibilityes
- 8+0.
- Gearless
- No
- Fast sleeve change
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1070
- Print width (mm)
- 1000
- Min print repeat (mm)
- 300
- Max print repeat (mm)
- 750
- Unwinder type
- Double spindle turret flying splice
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Double spindle turret flying splice
- Max reel diameter rewinder (mm)
- 800
- Drying
- Gas burner.
- Inking system
- solvent based. .8 ink pumps.Enclosed doctor blade chambers with ceramic anilox rollers
- Anilox
- 8 anilox ceramic coated and laser engraved.
- Note
- Substrates able to process:Plastic films Maximum speed :200 m./min. Bull-gear, pitch 5 mm. Edge guide systems:1 before printing and 1 before rewinding Length registers :Motorized remote controlled. Side registers:Manual. Decks’ positioning system:Automatic. Locking system of the printing units:Automatic.
| Machine Code | FL773 |
| Manufacturer | OFEM |
| Modello | JULIETTE 758 |
| Year | 2000 |
| Number of colors | 8 |
| Print possibilityes | 8+0. |
| Gearless | No |
| Fast sleeve change | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1070 |
| Print width (mm) | 1000 |
| Min print repeat (mm) | 300 |
| Max print repeat (mm) | 750 |
| Unwinder type | Double spindle turret flying splice |
| Max reel diameter unwinder (mm) | 800 |
| Rewinder type | Double spindle turret flying splice |
| Max reel diameter rewinder (mm) | 800 |
| Drying | Gas burner. |
| Inking system | solvent based. .8 ink pumps.Enclosed doctor blade chambers with ceramic anilox rollers |
| Anilox | 8 anilox ceramic coated and laser engraved. |
| Note | Substrates able to process:Plastic films Maximum speed :200 m./min. Bull-gear, pitch 5 mm. Edge guide systems:1 before printing and 1 before rewinding Length registers :Motorized remote controlled. Side registers:Manual. Decks’ positioning system:Automatic. Locking system of the printing units:Automatic. |
