Casemakers first print in flexo each colour required by the design. Cut of case's shape is performed in a rotary die cutter, which comprises a cylinder mounted with a cutting plate and an anvil cylinder. The anvil acts as a cutting plate, allowing cutting knives to penetrate the corrugated substrate and the creasing rules to create well defined creases. Waste is then stripped and finally a case ia formed in the folder gluer section.
Ask more informations
about a similar one
- Machine Code
- CB-CM25
- Manufacturer
- MARTIN
- Modello
- TRANSLINE 1228
- Year
- 1989
- Nominal Width (mm)
- 2800
- Max sheet width (mm)
- 2800
- Max sheet lenght (mm)
- 1250
- Pre feeder
- ASC Automaic prefeeder
- Printer
- Yes
- Num of colours
- 4
- Rotary die cutter
- Yes
- Slotter unit
- Automatic
- Folder gluer unit
- Yes
- Counter ejector
- Yes
- Note
- 4 bottom print flexo units with Rapidset system Straightline folding rails Multi-T belt system Valco electronic gluer
| Machine Code | CB-CM25 |
| Manufacturer | MARTIN |
| Modello | TRANSLINE 1228 |
| Year | 1989 |
| Nominal Width (mm) | 2800 |
| Max sheet width (mm) | 2800 |
| Max sheet lenght (mm) | 1250 |
| Pre feeder | ASC Automaic prefeeder |
| Printer | Yes |
| Num of colours | 4 |
| Rotary die cutter | Yes |
| Slotter unit | Automatic |
| Folder gluer unit | Yes |
| Counter ejector | Yes |
| Note | 4 bottom print flexo units with Rapidset system Straightline folding rails Multi-T belt system Valco electronic gluer |
