Lamination machines for flexible packaging industry are used to join together different webs creating a single web composed of a multi layer structure. Laminators coat a glue on a primary material and laminates secondary material onto it.
Ask more informations
- Machine Code
- LA497
- Manufacturer
- UTECO
- Modello
- Horizon
- Year
- 2000
- Application
- Lamination + coating
- Type of lamination/coating
- COMBI / INTECHANGEABLE TROLLEY
- Working width (mm)
- 1200
- Materials
- BOPP, PET, CPP, Al foil, LDPE , paper up to 120 gsm
- Speed
- 200 mpm
- First unwinder type
- Single position shafted
- Max diameter reel unwinder
- 800
- Secondary unwinder type
- Single position shafted
- Max diameter reel unwinder
- 800
- Rewinder type
- Single position shafted
- Max diameter reel rewinder
- 1000
- Coating unit
- Gravure
- Second Coating unitr
- Solventless
- Drying
- 2 zones double drying tunnel 2x 3 mt , 4 fans , thermo oil heat exchangers
- Register controll
- Yes for cold seal application
- pumping mixing unit
- Yes by VEA
- Note
- Two coating stands
| Machine Code | LA497 |
| Manufacturer | UTECO |
| Modello | Horizon |
| Year | 2000 |
| Application | Lamination + coating |
| Type of lamination/coating | COMBI / INTECHANGEABLE TROLLEY |
| Working width (mm) | 1200 |
| Materials | BOPP, PET, CPP, Al foil, LDPE , paper up to 120 gsm |
| Speed | 200 mpm |
| First unwinder type | Single position shafted |
| Max diameter reel unwinder | 800 |
| Secondary unwinder type | Single position shafted |
| Max diameter reel unwinder | 800 |
| Rewinder type | Single position shafted |
| Max diameter reel rewinder | 1000 |
| Coating unit | Gravure |
| Second Coating unitr | Solventless |
| Drying | 2 zones double drying tunnel 2x 3 mt , 4 fans , thermo oil heat exchangers |
| Register controll | Yes for cold seal application |
| pumping mixing unit | Yes by VEA |
| Note | Two coating stands |
