Coatings used in packaging industry are various. Cold and hot seal coating are common. Also, cold and hot seal coatings are commonly used, as well as hot melt and wax coatings. Silicon, Pvdc coating, ant mist and many others are employed. Materials which can be coated with a certain machine depends highly on the type of coating unit(s) available, on machine's construction and equipment.
Ask more informations
- Machine Code
- LA471
- Manufacturer
- ROTOMEC
- Modello
- M2
- Year
- 1984
- Application
- Coating
- Type of lamination/coating
- SOLVENT / WATER BASED
- Overhaul/renovation
- yes, in 2021
- Working width (mm)
- 1135
- Speed
- 200mpm
- First unwinder type
- Turret automatic
- Max diameter reel unwinder
- 1000
- Rewinder type
- Turret automatic
- Max diameter reel rewinder
- 1000
- Coating unit
- 1 gravure units
- Drying
- 4 hot air drying up to 150 degrees. Horizontal tunnel
- Note
- Rotomec air sleeve system NDC Coatwieght Scanner NDC Moister scanner Dr Schenk Web Detection 13 Spare cylinders 30 Spare Pressure Sleeves Water heating System - Tricol Lacquer Mix System - Spiroflow, including Hoppers, Screws and 2 holding tanks Safety Scanner unwind/rewind - 2 top, 2 bottom
| Machine Code | LA471 |
| Manufacturer | ROTOMEC |
| Modello | M2 |
| Year | 1984 |
| Application | Coating |
| Type of lamination/coating | SOLVENT / WATER BASED |
| Overhaul/renovation | yes, in 2021 |
| Working width (mm) | 1135 |
| Speed | 200mpm |
| First unwinder type | Turret automatic |
| Max diameter reel unwinder | 1000 |
| Rewinder type | Turret automatic |
| Max diameter reel rewinder | 1000 |
| Coating unit | 1 gravure units |
| Drying | 4 hot air drying up to 150 degrees. Horizontal tunnel |
| Note | Rotomec air sleeve system NDC Coatwieght Scanner NDC Moister scanner Dr Schenk Web Detection 13 Spare cylinders 30 Spare Pressure Sleeves Water heating System - Tricol Lacquer Mix System - Spiroflow, including Hoppers, Screws and 2 holding tanks Safety Scanner unwind/rewind - 2 top, 2 bottom |
