** SOLD **
Flexographic printing machines (often abbreviated as flexo press) perform a printing process which utilizes a flexible relief plate to transfer ink to printed substrate. Every printing job will require its dedicated set of plates.
Ask more informations
about a similar one
- Machine Code
- ST162
- Manufacturer
- TCM
- Year
- 1998
- Number of colors
- 8
- Print possibilityes
- 8+0, 4+4, 7+1, 5+3
- Type
- Reel to reel
- Web width (mm)
- 1450
- Print width (mm)
- 1400
- Print repeat (mm)
- 400-900 mm
- unwinder type
- Turret
- Max diameter reel unwinder (mm)
- 800
- Rewinder type
- Turret
- Max diameter reel rewinder (mm)
- 800
- Drying
- Gas burner
- Videocamera
- Yes,
- Inking sysytem
- Type of inks : water
- Anilox
- 8
- Print cylinders
- 8 x450-500-550-600-650-700-800-900mm
- Note
- Manual longitudinal/trasversal register. Helical clichè gears type. Gear pitch 10mm; Clichè thickness 2,54 + 0,5 ; Mechanical speed150.Printing speed 120.Max power installed 60. Ink distribution : idraulic motors; Materials : HTD LTD LPD BIO. Manual positioning system; Manual printing stations blocking system ; Vertical in/out printing. Ink feeding rubber roller.Pneumatic shafts 4 (76mm). Edge guide. 1 curved spreader rolls ; 48 gears.3 roller trolley. Power of essication 100.000 Kcal.
| Machine Code | ST162 |
| Manufacturer | TCM |
| Year | 1998 |
| Number of colors | 8 |
| Print possibilityes | 8+0, 4+4, 7+1, 5+3 |
| Type | Reel to reel |
| Web width (mm) | 1450 |
| Print width (mm) | 1400 |
| Print repeat (mm) | 400-900 mm |
| unwinder type | Turret |
| Max diameter reel unwinder (mm) | 800 |
| Rewinder type | Turret |
| Max diameter reel rewinder (mm) | 800 |
| Drying | Gas burner |
| Videocamera | Yes, |
| Inking sysytem | Type of inks : water |
| Anilox | 8 |
| Print cylinders | 8 x450-500-550-600-650-700-800-900mm |
| Note | Manual longitudinal/trasversal register. Helical clichè gears type. Gear pitch 10mm; Clichè thickness 2,54 + 0,5 ; Mechanical speed150.Printing speed 120.Max power installed 60. Ink distribution : idraulic motors; Materials : HTD LTD LPD BIO. Manual positioning system; Manual printing stations blocking system ; Vertical in/out printing. Ink feeding rubber roller.Pneumatic shafts 4 (76mm). Edge guide. 1 curved spreader rolls ; 48 gears.3 roller trolley. Power of essication 100.000 Kcal. |
