** SOLD **
Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".
Ask more informations
about a similar one
- Machine Code
- FL966
- Manufacturer
- FISCHER & KRECKE
- Modello
- FP A-8
- Year
- 2008
- Number of colors
- 8
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1300
- Print width (mm)
- 1250
- Min print repeat (mm)
- 320
- Max print repeat (mm)
- 880
- Unwinder type
- Turret shaftless
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Turret shaftless
- Max reel diameter rewinder (mm)
- 1000
- Drying
- Oil burner
- Videocamera
- Video AVT Jupiter dual mode, 2 monitors, defect detection system, preregister, Presco system and DeltaE-measuring
- Corona treatment
- Yes
- Web guides
- Before and after the printing unit
- Vyscosity control
- Viscosimeters type Viscolor 1000
- Washing system
- Autoclean system
- Inking system
- Closed chamber doctor blade
- Note
- Max mechanical speed 460 mt/min
Machine Code | FL966 |
Manufacturer | FISCHER & KRECKE |
Modello | FP A-8 |
Year | 2008 |
Number of colors | 8 |
Gearless | Yes |
Fast sleeve change | Yes |
4 motor per deck CNC position system | Yes |
Computer supervision | Yes |
Web width (mm) | 1300 |
Print width (mm) | 1250 |
Min print repeat (mm) | 320 |
Max print repeat (mm) | 880 |
Unwinder type | Turret shaftless |
Max reel diameter unwinder (mm) | 1000 |
Rewinder type | Turret shaftless |
Max reel diameter rewinder (mm) | 1000 |
Drying | Oil burner |
Videocamera | Video AVT Jupiter dual mode, 2 monitors, defect detection system, preregister, Presco system and DeltaE-measuring |
Corona treatment | Yes |
Web guides | Before and after the printing unit |
Vyscosity control | Viscosimeters type Viscolor 1000 |
Washing system | Autoclean system |
Inking system | Closed chamber doctor blade |
Note | Max mechanical speed 460 mt/min |
