** SOLD **
Flexographic printing machines (often abbreviated as flexo press) perform a printing process which utilizes a flexible relief plate to transfer ink to printed substrate. Every printing job will require its dedicated set of plates.
Ask more informations
about a similar one
- Machine Code
- FL966
- Manufacturer
- FISCHER & KRECKE
- Modello
- FP A-8
- Year
- 2008
- Number of colors
- 8
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1300
- Print width (mm)
- 1250
- Min print repeat (mm)
- 320
- Max print repeat (mm)
- 880
- Unwinder type
- Turret shaftless
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Turret shaftless
- Max reel diameter rewinder (mm)
- 1000
- Drying
- Oil burner
- Videocamera
- Video AVT Jupiter dual mode, 2 monitors, defect detection system, preregister, Presco system and DeltaE-measuring
- Corona treatment
- Yes
- Web guides
- Before and after the printing unit
- Vyscosity control
- Viscosimeters type Viscolor 1000
- Washing system
- Autoclean system
- Inking system
- Closed chamber doctor blade
- Note
- Max mechanical speed 460 mt/min
| Machine Code | FL966 |
| Manufacturer | FISCHER & KRECKE |
| Modello | FP A-8 |
| Year | 2008 |
| Number of colors | 8 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1300 |
| Print width (mm) | 1250 |
| Min print repeat (mm) | 320 |
| Max print repeat (mm) | 880 |
| Unwinder type | Turret shaftless |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | Turret shaftless |
| Max reel diameter rewinder (mm) | 1000 |
| Drying | Oil burner |
| Videocamera | Video AVT Jupiter dual mode, 2 monitors, defect detection system, preregister, Presco system and DeltaE-measuring |
| Corona treatment | Yes |
| Web guides | Before and after the printing unit |
| Vyscosity control | Viscosimeters type Viscolor 1000 |
| Washing system | Autoclean system |
| Inking system | Closed chamber doctor blade |
| Note | Max mechanical speed 460 mt/min |
