** SOLD **
Flexo presses are used to print on different supports: plastic films, paper and aluminium foil.
Ask more informations
about a similar one
- Machine Code
- FL921
- Manufacturer
- SCHIAVI
- Modello
- ALPHA
- Year
- 2001
- Number of colors
- 8
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1250
- Print width (mm)
- 1200
- Min print repeat (mm)
- 325
- Max print repeat (mm)
- 650
- Unwinder type
- TURRET
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- TURRET
- Max reel diameter rewinder (mm)
- 1000
- Drying
- 2 zones, 4 fans and 2 thermal oil heat exchangers. 1 zone inter colors 8.500m3/h, second zone is drying tunnel 10.300 m3/h: 2 x 18 nozels, tot 4,5 m length, Infrared lamps
- Videocamera
- BST
- Corona treatment
- yes
- Web guides
- 2 in and out
- Vyscosity control
- New celio
- Inking system
- Closed chamber doctor blades
- Print Sleeves
- approx 310 sleeves + approx 24 bridge sleeves/adapters
- Note
- CI drum diam 1800mm Hastelly surface Materials: Film from 10 my, Alu foil from 7 my, paper and laminates up to 120 gsm Plate thickness 1,14mm + 0,55mm Thermo regulation for CI drum LEL contol system Zellweger speed 350 m/min
Machine Code | FL921 |
Manufacturer | SCHIAVI |
Modello | ALPHA |
Year | 2001 |
Number of colors | 8 |
Gearless | Yes |
Fast sleeve change | Yes |
4 motor per deck CNC position system | Yes |
Computer supervision | Yes |
Web width (mm) | 1250 |
Print width (mm) | 1200 |
Min print repeat (mm) | 325 |
Max print repeat (mm) | 650 |
Unwinder type | TURRET |
Max reel diameter unwinder (mm) | 1000 |
Rewinder type | TURRET |
Max reel diameter rewinder (mm) | 1000 |
Drying | 2 zones, 4 fans and 2 thermal oil heat exchangers. 1 zone inter colors 8.500m3/h, second zone is drying tunnel 10.300 m3/h: 2 x 18 nozels, tot 4,5 m length, Infrared lamps |
Videocamera | BST |
Corona treatment | yes |
Web guides | 2 in and out |
Vyscosity control | New celio |
Inking system | Closed chamber doctor blades |
Print Sleeves | approx 310 sleeves + approx 24 bridge sleeves/adapters |
Note | CI drum diam 1800mm Hastelly surface Materials: Film from 10 my, Alu foil from 7 my, paper and laminates up to 120 gsm Plate thickness 1,14mm + 0,55mm Thermo regulation for CI drum LEL contol system Zellweger speed 350 m/min |
