SCHIAVI BOBST ALPHA Flexo central drum printing press 8 colors

Flexographic printing machines (often abbreviated as flexo press) perform a printing process which utilizes a flexible relief plate to transfer ink to printed substrate. Every printing job will require its dedicated set of plates.

Machine Code FL902
Manufacturer SCHIAVI BOBST
Model ALPHA
Year 2000
Number of colors 8
Print possibilities 8+0
Gearless Yes
Fast sleeve change Yes
4 motor per deck CNC position system Yes
Computer supervision Yes
Web width (mm) 1120
Print width (mm) 1050
Min print repeat (mm) 300
Max print repeat (mm) 650
Unwinder type Turret
Max reel diameter unwinder (mm) 1000
Rewinder type Turret
Max reel diameter rewinder (mm) 1000
Drying Gas
Videocamera BST
Corona treatment Mero
Web guides 2 BST
Vyscosity control Yes
Washing system No
Inking system Closed chamber doctor blades + ceramic anilox
Anilox 8
Print Sleeves 150
Additional information Number of carrier sleeves 114,708-8pcs & 140,173-8pcs Max. mechanical speed: Max 350 Thickness: Min 12 my
