** SOLD **
Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".
Ask more informations
about a similar one
- Machine Code
- FL803
- Manufacturer
- UTECO
- Modello
- EMERALD 107
- Year
- 2003
- Number of colors
- 10
- Print possibilityes
- 10+Solventless lamination
- Overhaul/renovation
- Major overhaul during 2016-1017, new washing system, new chamber doctor blades, new viscosity control, new videocamera, check up of bearings, mandrels re-balancing, part of sleeves and aniloxes were bought new in 2017.
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1250
- Print width (mm)
- 1200
- Min print repeat (mm)
- 350
- Max print repeat (mm)
- 800
- Unwinder type
- Turret automatic
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Turret automatic
- Max reel diameter rewinder (mm)
- 800
- Drying
- 2 drying zones- 4 fans- final tunnel 6 mt length, hot water heat exchangers , automatic recirculation system with Heck controll
- Videocamera
- yes BST Eltromat new 2016, secon bd video camera E&L for back side inspection
- Corona treatment
- yes two Corona treaters F&B one before printing , second for secondary unwinder for material to be laminated
- Web guides
- yes
- Vyscosity control
- yes new Gama 2017
- Washing system
- yes
- Inking system
- doctor blades - new 2016
- Anilox
- 40 ceramic anilox sleeves
- Print Sleeves
- 800 totally
- Note
- 10 color CI with solventless lamination in line
| Machine Code | FL803 |
| Manufacturer | UTECO |
| Modello | EMERALD 107 |
| Year | 2003 |
| Number of colors | 10 |
| Print possibilityes | 10+Solventless lamination |
| Overhaul/renovation | Major overhaul during 2016-1017, new washing system, new chamber doctor blades, new viscosity control, new videocamera, check up of bearings, mandrels re-balancing, part of sleeves and aniloxes were bought new in 2017. |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1250 |
| Print width (mm) | 1200 |
| Min print repeat (mm) | 350 |
| Max print repeat (mm) | 800 |
| Unwinder type | Turret automatic |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | Turret automatic |
| Max reel diameter rewinder (mm) | 800 |
| Drying | 2 drying zones- 4 fans- final tunnel 6 mt length, hot water heat exchangers , automatic recirculation system with Heck controll |
| Videocamera | yes BST Eltromat new 2016, secon bd video camera E&L for back side inspection |
| Corona treatment | yes two Corona treaters F&B one before printing , second for secondary unwinder for material to be laminated |
| Web guides | yes |
| Vyscosity control | yes new Gama 2017 |
| Washing system | yes |
| Inking system | doctor blades - new 2016 |
| Anilox | 40 ceramic anilox sleeves |
| Print Sleeves | 800 totally |
| Note | 10 color CI with solventless lamination in line |
