WINDMÖLLER & HÖLSCHER NOVOFLEX flexo press 8 colors // Flexo CI // Printing machines // Used Flexo Press // Tecno Converting 2000 S.r.l.

** SOLD **

Flexographic printing machines (often abbreviated as flexo press) perform a printing process which utilizes a flexible relief plate to transfer ink to printed substrate. Every printing job will require its dedicated set of plates.

Photo Gallery

Ask more informations

about a similar one

Machine Code: FL890
Manufacturer: WINDMÖLLER & HÖLSCHER
Modello: NOVOFLEX
Year: 2002
Number of colors: 8
Print possibilityes: 8+0
Gearless: Yes
Fast sleeve change: Yes
4 motor per deck CNC position system: Yes
Computer supervision: Yes
Web width (mm): 1050
Print width (mm): 1000
Min print repeat (mm): 300
Min print repeat (mm): 300
Max print repeat (mm): 760
Unwinder type: TURRET
Max reel diameter unwinder (mm): 1000
Rewinder type: TURRET
Max reel diameter rewinder (mm): 1000
Videocamera: Eltromat from 2016 with registration system
Corona treatment: Softal
Vyscosity control: no
Washing system: no
Inking system: Closed cha,ber doctor blades
Inking system: Closed chamber doctor baldes
Anilox: 43 ceramic anilox sleeves as follows 2 x 400 l/cm Vol. 4,3 ; 6x 400 L/cm-V 4,5 ; 4x 400 l/cm V.4,7; 4x 320 l/cm-V.5 ; 1x 320 l/cm-V5,5; 1x 320 l/cm V.5,7 ; 1x 315 l/cm-Vol.5,2 ; 2x 315 l/cm -V. 5,8; 2 x 285 l/cm.V.9,5 ; 4x 280 l/cm-V.8,5 ; 1x 280 l/cm-V.7 ; 2x 220 l/cm V.9,1 ;1x 180 l/cm-v.9,2 ; 1x 180 l/cm.V.9,6 ; 3x 160 l/cm-v.12 ; 2x 160 l/cm-V.12,3 ; 2x 140 l/cm -v.14 ; 1x 140 l/cm v.12,3 ; 2 x100 l/cm-v.14,2; 2x 100 l/cm-v.15,1; 1x 100 l/cm-v.22
Anilox: 45 Anilox sleeves: 5x100 L/cm, 3x140 L/cm, 5x160 L/cm, 2x180 L/cm, 2x220 L/cm, 5x280 L/cm, 2x285 L/cm, 3x315 L/cm, 6x320 L/cm, 12x400 L/cm
Print Sleeves: Tot 292 print repeats: 300x16,315x16, 325x15, 330x7, 340x8, 350x8, 365x8, 380x8, 400x16, 410x16, 420x16, 425x8, 430x16, 440x8, 450x16, 460x8, 470x16, 480x8, 490x12, 500x10, 520x16, 540x8, 560x8, 580x8, 640x8, 680x8, 690x8

Machine Code	FL890
Manufacturer	WINDMÖLLER & HÖLSCHER
Modello	NOVOFLEX
Year	2002
Number of colors	8
Print possibilityes	8+0
Gearless	Yes
Fast sleeve change	Yes
4 motor per deck CNC position system	Yes
Computer supervision	Yes
Web width (mm)	1050
Print width (mm)	1000
Min print repeat (mm)	300
Min print repeat (mm)	300
Max print repeat (mm)	760
Unwinder type	TURRET
Max reel diameter unwinder (mm)	1000
Rewinder type	TURRET
Max reel diameter rewinder (mm)	1000
Videocamera	Eltromat from 2016 with registration system
Corona treatment	Softal
Vyscosity control	no
Washing system	no
Inking system	Closed cha,ber doctor blades
Inking system	Closed chamber doctor baldes
Anilox	43 ceramic anilox sleeves as follows 2 x 400 l/cm Vol. 4,3 ; 6x 400 L/cm-V 4,5 ; 4x 400 l/cm V.4,7; 4x 320 l/cm-V.5 ; 1x 320 l/cm-V5,5; 1x 320 l/cm V.5,7 ; 1x 315 l/cm-Vol.5,2 ; 2x 315 l/cm -V. 5,8; 2 x 285 l/cm.V.9,5 ; 4x 280 l/cm-V.8,5 ; 1x 280 l/cm-V.7 ; 2x 220 l/cm V.9,1 ;1x 180 l/cm-v.9,2 ; 1x 180 l/cm.V.9,6 ; 3x 160 l/cm-v.12 ; 2x 160 l/cm-V.12,3 ; 2x 140 l/cm -v.14 ; 1x 140 l/cm v.12,3 ; 2 x100 l/cm-v.14,2; 2x 100 l/cm-v.15,1; 1x 100 l/cm-v.22
Anilox	45 Anilox sleeves: 5x100 L/cm, 3x140 L/cm, 5x160 L/cm, 2x180 L/cm, 2x220 L/cm, 5x280 L/cm, 2x285 L/cm, 3x315 L/cm, 6x320 L/cm, 12x400 L/cm
Print Sleeves	Tot 292 print repeats: 300x16,315x16, 325x15, 330x7, 340x8, 350x8, 365x8, 380x8, 400x16, 410x16, 420x16, 425x8, 430x16, 440x8, 450x16, 460x8, 470x16, 480x8, 490x12, 500x10, 520x16, 540x8, 560x8, 580x8, 640x8, 680x8, 690x8
