** SOLD **
Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".
Ask more informations
about a similar one
- Machine Code
- FL716
- Manufacturer
- COMEXI
- Modello
- FI2508
- Year
- 2006
- Number of colors
- 8
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1470
- Print width (mm)
- 1420
- Min print repeat (mm)
- 400
- Max print repeat (mm)
- 1350
- Unwinder type
- AUTOMATIC TURRET
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- AUTOMATIC TURRET
- Max reel diameter rewinder (mm)
- 1000
- Drying
- Thermaoil( central system) and gas
- Videocamera
- AVT Jupiter
- Corona treatment
- yes Softal
- Web guides
- 2
- Vyscosity control
- yes automatic
- Washing system
- AUTOMATIC
- Inking system
- closed chamber doctor blades
- Anilox
- 26 ceramic anilox sleeves as follows 1x 65 l/ cm-HVP vol.14 cm3/m2 ;1x 100 l/cm,-vol.10,2 cm3/m2 ; 5 x 140 l/ cm Vol 8,05 cm3/m2 ; 2 x 140 L/cm,- vol 8,2 ; 1X 160 L/CM hvp VOL.14,0 ; 3 x 215 ll/cm- vol.6,0 ; 1 X 140 L/CM-VOL.6,0; 2 x 215 l/ cm- vol.6,3 ; 8 x 300 l/ cm -vol.4,,2 ;,6 x 360 l/cm.
- Print Sleeves
- TOTALLY 64 SLEEVES 15x 400 mm, 7x 410 , 8x 440 , 8x 460 ; 7x 520 ; 1x 540 ; 1x 610 ; 8x 800
- Print cylinders
- Carbon fiber Carriers 8x 480mm; 8x 580mm; 8x680 ; 8x 880 ; 8x 980 ; 8 x 1180 .
- Note
- temperature control unit for CI 4 spare chamber doctor blades spare ink tanks and lids ink pumps div. sleeves div. anilox rollers Longitudinal and side register motorized Automatic register control Electr. container
Machine Code | FL716 |
Manufacturer | COMEXI |
Modello | FI2508 |
Year | 2006 |
Number of colors | 8 |
Gearless | Yes |
Fast sleeve change | Yes |
4 motor per deck CNC position system | Yes |
Computer supervision | Yes |
Web width (mm) | 1470 |
Print width (mm) | 1420 |
Min print repeat (mm) | 400 |
Max print repeat (mm) | 1350 |
Unwinder type | AUTOMATIC TURRET |
Max reel diameter unwinder (mm) | 1000 |
Rewinder type | AUTOMATIC TURRET |
Max reel diameter rewinder (mm) | 1000 |
Drying | Thermaoil( central system) and gas |
Videocamera | AVT Jupiter |
Corona treatment | yes Softal |
Web guides | 2 |
Vyscosity control | yes automatic |
Washing system | AUTOMATIC |
Inking system | closed chamber doctor blades |
Anilox | 26 ceramic anilox sleeves as follows 1x 65 l/ cm-HVP vol.14 cm3/m2 ;1x 100 l/cm,-vol.10,2 cm3/m2 ; 5 x 140 l/ cm Vol 8,05 cm3/m2 ; 2 x 140 L/cm,- vol 8,2 ; 1X 160 L/CM hvp VOL.14,0 ; 3 x 215 ll/cm- vol.6,0 ; 1 X 140 L/CM-VOL.6,0; 2 x 215 l/ cm- vol.6,3 ; 8 x 300 l/ cm -vol.4,,2 ;,6 x 360 l/cm. |
Print Sleeves | TOTALLY 64 SLEEVES 15x 400 mm, 7x 410 , 8x 440 , 8x 460 ; 7x 520 ; 1x 540 ; 1x 610 ; 8x 800 |
Print cylinders | Carbon fiber Carriers 8x 480mm; 8x 580mm; 8x680 ; 8x 880 ; 8x 980 ; 8 x 1180 . |
Note | temperature control unit for CI 4 spare chamber doctor blades spare ink tanks and lids ink pumps div. sleeves div. anilox rollers Longitudinal and side register motorized Automatic register control Electr. container |
