COMEXI FP GL 1808 Flexo central drum printing press 8 colors

** SOLD **

Flexo presses are used to print on different supports: plastic films, paper and aluminium foil.

Ask more informations
about a similar one
Machine Code
FL735
Manufacturer
COMEXI
Model
FP GL 1808
Year
2002
Number of colors
8
Gearless
Yes
Fast sleeve change
Yes
4 motor per deck CNC position system
Yes
Computer supervision
Yes
Web width (mm)
1270
Print width (mm)
1220
Min print repeat (mm)
350
Max print repeat (mm)
680
Unwinder type
TURRET WITH SPLICE
Max reel diameter unwinder (mm)
800
Rewinder type
TURRET WITH SPLICE
Max reel diameter rewinder (mm)
800
Drying
2 zone drying 4 fans 2 gas burners drying lenght 7.2 mtrs
Videocamera
AVT Genius
Corona treatment
Albrandt
Web guides
BST
Vyscosity control
Inelme automatic
Washing system
Semi automatic
Inking system
Closed chabers doctor blades
Anilox
14 as follows: 2x10.8V;1x10V;1x14V;1x11V;1x6.5V;1x6V;2x9V;1x4.2V;4x3.4V
Print Sleeves
218 as follows: 16x375,380, 480,500; 8x385,455,470,520,530,535,560,570,580,590,610,630mm; 10x460,510mm; 14x540mm
Additional information
mechanical speed 350 m/min Inline slitting, blades and roller , no extract fan Materials LDPE, OPP, CPP
Machine Code FL735
Manufacturer COMEXI
Model FP GL 1808
Year 2002
Number of colors 8
Gearless Yes
Fast sleeve change Yes
4 motor per deck CNC position system Yes
Computer supervision Yes
Web width (mm) 1270
Print width (mm) 1220
Min print repeat (mm) 350
Max print repeat (mm) 680
Unwinder type TURRET WITH SPLICE
Max reel diameter unwinder (mm) 800
Rewinder type TURRET WITH SPLICE
Max reel diameter rewinder (mm) 800
Drying 2 zone drying 4 fans 2 gas burners drying lenght 7.2 mtrs
Videocamera AVT Genius
Corona treatment Albrandt
Web guides BST
Vyscosity control Inelme automatic
Washing system Semi automatic
Inking system Closed chabers doctor blades
Anilox 14 as follows: 2x10.8V;1x10V;1x14V;1x11V;1x6.5V;1x6V;2x9V;1x4.2V;4x3.4V
Print Sleeves 218 as follows: 16x375,380, 480,500; 8x385,455,470,520,530,535,560,570,580,590,610,630mm; 10x460,510mm; 14x540mm
Additional information mechanical speed 350 m/min Inline slitting, blades and roller , no extract fan Materials LDPE, OPP, CPP
** SOLD **
