- Code Machine
- FL451
- Fabricant
- BIELLONI
- Modello
- REGINA EASY
- Année
- 1995
- Number of colors
- 8
- Gearless
- No
- Fast sleeve change
- No
- Web width (mm)
- 1470
- Print width (mm)
- 1400
- Min print repeat (mm)
- 350
- Max print repeat (mm)
- 800
- Unwinder type
- Turret
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Turret
- Max reel diameter rewinder (mm)
- 1000
- Drying
- Electric heaters
- Videocamera
- Crossfield (not working)
- Web guides
- Before and after printing
- Vyscosity control
- Crossfield (not working)
- Inking system
- yes
- Anilox
- 12, 180 l/cm / 8 cm³/m² ( 1pcs ) ;220 l/cm / 6 cm³/m² ( 4pcs ) ;260 l/cm /5 cm³/m² ( 1pcs ) ;120 l/cm / 11 cm³/m² ( 1pcs ) ;140 l/cm / 15 cm³/m² ( 1pcs ) ; 100 l/cm / 16 cm³/m² ( 1pcs )
- Print cylinders
- 8 x 385, 400, 410, 450, 470, 510, 530, 550, 610, 650, 720
- Note
- CI gear type; Speed: 100 -150m/min; Chill role unit; Bridge with air dryer; Unwinder/rewinder include two air shafts. ;Spare rollers ± 6 pieces
Code Machine | FL451 |
Fabricant | BIELLONI |
Modello | REGINA EASY |
Année | 1995 |
Number of colors | 8 |
Gearless | No |
Fast sleeve change | No |
Web width (mm) | 1470 |
Print width (mm) | 1400 |
Min print repeat (mm) | 350 |
Max print repeat (mm) | 800 |
Unwinder type | Turret |
Max reel diameter unwinder (mm) | 1000 |
Rewinder type | Turret |
Max reel diameter rewinder (mm) | 1000 |
Drying | Electric heaters |
Videocamera | Crossfield (not working) |
Web guides | Before and after printing |
Vyscosity control | Crossfield (not working) |
Inking system | yes |
Anilox | 12, 180 l/cm / 8 cm³/m² ( 1pcs ) ;220 l/cm / 6 cm³/m² ( 4pcs ) ;260 l/cm /5 cm³/m² ( 1pcs ) ;120 l/cm / 11 cm³/m² ( 1pcs ) ;140 l/cm / 15 cm³/m² ( 1pcs ) ; 100 l/cm / 16 cm³/m² ( 1pcs ) |
Print cylinders | 8 x 385, 400, 410, 450, 470, 510, 530, 550, 610, 650, 720 |
Note | CI gear type; Speed: 100 -150m/min; Chill role unit; Bridge with air dryer; Unwinder/rewinder include two air shafts. ;Spare rollers ± 6 pieces |
