UTECO ONYX 865 XS Imprimeus Flexo 8 couleurs // Flexo CI // Printing machines // Équipement d'occasion // Tecno Converting 2000 S.r.l.

Photo Gallerie

Demander plus d'informations

Code Machine: FL1107
Fabricant: UTECO
Modello: ONYX 865 XS
Année: 2018
Number of colors: 8
Print possibilityes: 8+0
Gearless: Yes
Fast sleeve change: Yes
4 motor per deck CNC position system: Yes
Computer supervision: Yes
Web width (mm): 1050
Print width (mm): 1020
Min print repeat (mm): 300
Max print repeat (mm): 650
Unwinder type: Single position Shaftless Ac motor driven
Max reel diameter unwinder (mm): 1000
Rewinder type: Turret automatic with splicing in both directions.
Max reel diameter rewinder (mm): 1000
Drying: 2 zones , Electric heaters with automatic temp . preset and control . Automatic air recirculation system with LEL control
Videocamera: Video Camera Grafikontrol Matrix 3CCD with register adjustment. Click&Drag
Corona treatment: Yes Ferrarini Benelli Polymetal suitable for metallized films
Web guides: yes in and out Fife OPG
Vyscosity control: Yes Automatic Gama G29
Washing system: Yes automatic Solvent tanks included. Distillation available for additional cost
Inking system: Closed chamber doctor blades and ceramic anilox sleevs
Anilox: 18 ceramic anilox sleeves APEX.11 are GTT type. 6 x mod T.S, 2xT.M, 4xT.L, 2x T.XL, 1 with traditional engraving
Print Sleeves: 280 print sleeves. Repeat 310, 320, 330, 340, 350, 360, 370, 380, 390, 400, 410, 420, 430, 440, 450, 460, 470, 480, 490, 500, 510, 520, 530, 540, 550, 560, 570, 580, 590, 600, 610, 620, 630, 640, 650 mm x 8 sleeves for each repeat + 9 carrier adaptors for repeats above 500mm
Note: Hastalloy coated CI drum Automatic print posion setting " Touch and Go" position of printing decks. P2P automatic print pressure adjustments with speed Automatic Print pre register system and pre setting system Tune&Go Remote Technical Assistance connection. Reprint function on preprinted web ,complete with automatic insetting register control . Uteco Production management control SQL Chiller for CI drum and outfeed chill roller nip INCLUDED Suitable for both water based and solvent based inks

Code Machine	FL1107
Fabricant	UTECO
Modello	ONYX 865 XS
Année	2018
Number of colors	8
Print possibilityes	8+0
Gearless	Yes
Fast sleeve change	Yes
4 motor per deck CNC position system	Yes
Computer supervision	Yes
Web width (mm)	1050
Print width (mm)	1020
Min print repeat (mm)	300
Max print repeat (mm)	650
Unwinder type	Single position Shaftless Ac motor driven
Max reel diameter unwinder (mm)	1000
Rewinder type	Turret automatic with splicing in both directions.
Max reel diameter rewinder (mm)	1000
Drying	2 zones , Electric heaters with automatic temp . preset and control . Automatic air recirculation system with LEL control
Videocamera	Video Camera Grafikontrol Matrix 3CCD with register adjustment. Click&Drag
Corona treatment	Yes Ferrarini Benelli Polymetal suitable for metallized films
Web guides	yes in and out Fife OPG
Vyscosity control	Yes Automatic Gama G29
Washing system	Yes automatic Solvent tanks included. Distillation available for additional cost
Inking system	Closed chamber doctor blades and ceramic anilox sleevs
Anilox	18 ceramic anilox sleeves APEX.11 are GTT type. 6 x mod T.S, 2xT.M, 4xT.L, 2x T.XL, 1 with traditional engraving
Print Sleeves	280 print sleeves. Repeat 310, 320, 330, 340, 350, 360, 370, 380, 390, 400, 410, 420, 430, 440, 450, 460, 470, 480, 490, 500, 510, 520, 530, 540, 550, 560, 570, 580, 590, 600, 610, 620, 630, 640, 650 mm x 8 sleeves for each repeat + 9 carrier adaptors for repeats above 500mm
Note	Hastalloy coated CI drum Automatic print posion setting " Touch and Go" position of printing decks. P2P automatic print pressure adjustments with speed Automatic Print pre register system and pre setting system Tune&Go Remote Technical Assistance connection. Reprint function on preprinted web ,complete with automatic insetting register control . Uteco Production management control SQL Chiller for CI drum and outfeed chill roller nip INCLUDED Suitable for both water based and solvent based inks
