- Código Máquina
- SR404
- Constructor
- BIMEC
- Modello
- STB/60
- Año
- 1995
- Overhaul/renovation
- renovated in 2013
- Working width (mm)
- 1100
- Speed
- 300 m/min
- Unwinder type
- Shafted
- Max diameter reel unwinder
- 1000
- Rewinder type
- Double shaft center driven
- Max diameter reel rewinder
- 600
- Min slit width
- 40mm
- Knives
- 12 Rotary Knives. 12 Counterknives.Shaft for cutting blades
- Note
- Weight : 3000 kg Operating voltage: 380 V/50 Hz Absorption: 18 KW Line Cable Section CU (copper): 10 mm2 Working pressure: 6 ÷ 7 BAR Continuous acoustic pressure level: (A) < 80 DB
Código Máquina | SR404 |
Constructor | BIMEC |
Modello | STB/60 |
Año | 1995 |
Overhaul/renovation | renovated in 2013 |
Working width (mm) | 1100 |
Speed | 300 m/min |
Unwinder type | Shafted |
Max diameter reel unwinder | 1000 |
Rewinder type | Double shaft center driven |
Max diameter reel rewinder | 600 |
Min slit width | 40mm |
Knives | 12 Rotary Knives. 12 Counterknives.Shaft for cutting blades |
Note | Weight : 3000 kg Operating voltage: 380 V/50 Hz Absorption: 18 KW Line Cable Section CU (copper): 10 mm2 Working pressure: 6 ÷ 7 BAR Continuous acoustic pressure level: (A) < 80 DB |
