- Código Máquina
- SR651
- Constructor
- KAMPF
- Modello
- CONSLIT
- Año
- 2010
- Working width (mm)
- 1650
- Materials
- Plastic films : LLDPE approx. 12µ, Embossed LDPE 14 gsm, BOPP also metallized, laminates with aluminium up to 120µ
- Speed
- 600m/min
- Unwinder type
- Shaftless
- Max diameter reel unwinder
- 1300
- Rewinder type
- Center driven with independent arms
- Max diameter reel rewinder
- 610
- Min slit width
- 50mm
- Knives
- scissors cut, add. option razor blade cut
- Note
- PLC - Siemens S7-400
| Código Máquina | SR651 |
| Constructor | KAMPF |
| Modello | CONSLIT |
| Año | 2010 |
| Working width (mm) | 1650 |
| Materials | Plastic films : LLDPE approx. 12µ, Embossed LDPE 14 gsm, BOPP also metallized, laminates with aluminium up to 120µ |
| Speed | 600m/min |
| Unwinder type | Shaftless |
| Max diameter reel unwinder | 1300 |
| Rewinder type | Center driven with independent arms |
| Max diameter reel rewinder | 610 |
| Min slit width | 50mm |
| Knives | scissors cut, add. option razor blade cut |
| Note | PLC - Siemens S7-400 |
