5 capas TECHNO COATING ENGINEERING Extrusora de film ** VENDIDA ** Informaciones adicionales sobre una similar
| Código Máquina | CA135 |
| Constructor | TECHNO COATING ENGINEERING |
| Año | 2001 |
| Numero de capas | 5 |
| Estructura film | couches A-C-B-C-D percentage 10%-20%-40%-20%-10% à 20%-15%-30%-15%-20% |
| Material | LLDPE stretch film 12 - 60my |
| Ancho del film (mm) | 3000 |
| Velocidad (m/min) | 600 |
| Producción (kg/h) | net film: 1800 Kg/h ; Output on 23my 1700Kg/h at 450 m/min |
| Extrusora 1 capa rif: | A |
| Diametro tornillo | 130mm |
| Descripción | L/D 30; Bimetallic barrel; Gravimetric doser; Motor 250Kw; hydraulic screen changer |
| Extrusora 2 capa rif: | B |
| Diametro tornillo | 160mm |
| Descripción | L/D 30; Bimetallic barrel; Gravimetric doserc; Motor 350Kw; 2x forced feeding for edge trim re-feeding system 130mm L/D6; hydraulic screen changer |
| Extrusora 3 capa rif: | C |
| Diametro tornillo | 160mm |
| Descripción | L/D 30; Bimetallic barrel; Gravimetric doser; Motor 350Kw; hydraulic screen changer |
| Extrusora 4 capa rif: | D |
| Diametro tornillo | 130mm |
| Descripción | L/D 30; Bimetallic barrel; Gravimetric doser; Motor 250Kw; hydraulic screen changer |
| Descripción cabezal | Automatic die, Flex lip and thermobolt. Make EDI model: Autoflex 3700 m/m IV H40;Year 2010 . Die gap 0,1-1mm; Vacuum Box |
| Die width (mm) | 3700 |
| Calandra de enfriamiento | chill roll width 3800mm; firs chill roll diameter 980mm; Electrostati edge pinning system ELTEX; |
| Sistema control de espesor | Automatic. Make Electronic System model CTW-5000 ; double gauge thickness reading system with Beta rays, complete with control panel and feedback on thermobolts system |
| Alineador | E+L |
| Descripción enrollador | Rewinder for Jumbo reels and machine reels. Automaticreel change, reels extraction and new core position system. contact roller diam 495mm; |
| Informaciones adicionales | - Water termoregutation and pumping unit - Edge trim and in line re-feeding system into B extruder - Components : PLC: SIEMENS S7 400 Drives : SIEMENS INVERTERS : SIEMENS Relais temporized : Weimuller Pneumatic components : CEMA Hydraulic components : Norgen Ball bearings : SKF Motors DC : SIEMENS Motors AC : Bima/SIEMENS Available several spare parts among which a spare die. |
** VENDIDA **
