** SOLD **
Cast film extrusion lines are commonly used to extrude plastic films especially for flexible packaging industry. / In a cast film extruder PE, PP or PA granulates (or other polymers) are melted inro an extruder and pushed through a flat extrusion die (T die), extruding a sheet of molten polymer onto a cooled roller (chill roll).
Ask more informations
about a similar one
- Machine Code
- CA099
- Manufacturer
- DOLCI
- Modello
- NEXTROM
- Year
- 2000
- Number of layers
- 3
- Film structure
- ABC
- Material
- Stretch film LLDPE
- Film width (mm)
- 2000
- Speed (m/min)
- 450
- Output (Kg/h)
- 1000-1100
- Extruder 1 Layer ref:
- A
- Screw diam 1
- 90MM
- Description 1
- L/D30, 144,6KW ; Dosing system 3 components
- Extruder 2 Layer ref:
- B
- Screw diam 2
- 160MM
- Description 2
- L/D 30 , 324 KW; Dosing system 3 components
- Extruder 3 Layer ref:
- C
- Screw diam 3
- 90MM
- Description 3
- L/D30, 144,6KW; Dosing system 3 components
- Head description
- Automatic - Simplas
- Chill roll unit
- 1 chill roll diam.1000mm ; 1 chill roll diam. 450mm;
- Thickness controll system
- Scanner thickness Beta Rays - Electronics
- Rewinder max reel diameter (mm)
- 500mm
- Rewinder description
- Type of reels: jumbo & reels for wrapping machine.Fully Automatic ; Automatic cores loading on shaft (Rebotic ) ; Automatic finished reels unloading ( Robotic )
- Note
- Dimensions : width 6000 ; length : 21000mm ; height : 8000mm (included dosing system ) Thickness range 12-50my. Trim recycling system Soundproof booth equipped of grinder machine Oscillating unit Fife double side PLC control Siemens S7 Production for jumbo roll cores 76mm; production capacity( 23my -450m/min ) - 1150 kg/h edge trims : automatic, equipped of grinder machine; automatic trims recycling system in line;
Machine Code | CA099 |
Manufacturer | DOLCI |
Modello | NEXTROM |
Year | 2000 |
Number of layers | 3 |
Film structure | ABC |
Material | Stretch film LLDPE |
Film width (mm) | 2000 |
Speed (m/min) | 450 |
Output (Kg/h) | 1000-1100 |
Extruder 1 Layer ref: | A |
Screw diam 1 | 90MM |
Description 1 | L/D30, 144,6KW ; Dosing system 3 components |
Extruder 2 Layer ref: | B |
Screw diam 2 | 160MM |
Description 2 | L/D 30 , 324 KW; Dosing system 3 components |
Extruder 3 Layer ref: | C |
Screw diam 3 | 90MM |
Description 3 | L/D30, 144,6KW; Dosing system 3 components |
Head description | Automatic - Simplas |
Chill roll unit | 1 chill roll diam.1000mm ; 1 chill roll diam. 450mm; |
Thickness controll system | Scanner thickness Beta Rays - Electronics |
Rewinder max reel diameter (mm) | 500mm |
Rewinder description | Type of reels: jumbo & reels for wrapping machine.Fully Automatic ; Automatic cores loading on shaft (Rebotic ) ; Automatic finished reels unloading ( Robotic ) |
Note | Dimensions : width 6000 ; length : 21000mm ; height : 8000mm (included dosing system ) Thickness range 12-50my. Trim recycling system Soundproof booth equipped of grinder machine Oscillating unit Fife double side PLC control Siemens S7 Production for jumbo roll cores 76mm; production capacity( 23my -450m/min ) - 1150 kg/h edge trims : automatic, equipped of grinder machine; automatic trims recycling system in line; |
