** SOLD **
Cast film extrusion lines are commonly used to extrude plastic films especially for flexible packaging industry. / In a cast film extruder PE, PP or PA granulates (or other polymers) are melted inro an extruder and pushed through a flat extrusion die (T die), extruding a sheet of molten polymer onto a cooled roller (chill roll).
Ask more informations
about a similar one
- Machine Code
- CA142
- Manufacturer
- TECHNO COATING ENGINEERING
- Year
- 2001
- Number of layers
- 5
- Material
- Stretch film LLDPE
- Film width (mm)
- 3000
- Extruder 1 Layer ref:
- A
- Screw diam 1
- 130 mm
- Description 1
- L/D 30; Bimetallic barrel; Gravimetric doser; Motor 250Kw; hydraulic screen changer
- Extruder 2 Layer ref:
- B
- Screw diam 2
- 160 mm
- Description 2
- L/D 30; Bimetallic barrel; Gravimetric doserc; Motor 350Kw; 2x forced feeding for edge trim re-feeding system 130mm L/D6; hydraulic screen changer
- Extruder 3 Layer ref:
- C
- Screw diam 3
- 160 mm
- Description 3
- L/D 30; Bimetallic barrel; Gravimetric doser; Motor 350Kw; hydraulic screen changer
- Extruder 4 Layer ref:
- D
- Screw diam 4
- 130 mm
- Description 4
- L/D 30; Bimetallic barrel; Gravimetric doser; Motor 250Kw; hydraulic screen changer
- Head description
- Automatic die, Flex lip and thermobolt. Make EDI model: Autoflex 3700 m/m IV H40;Year 2010 . Die gap 0,1-1mm; Vacuum Box
- Die width (mm)
- 3700
- Chill roll unit
- chill roll width 3800mm; firs chill roll diameter 980mm; Electrostati edge pinning system ELTEX;
- Thickness controll system
- Automatic. Make Electronic System model CTW-5000 ; double gauge thickness reading system with Beta rays, complete with control panel and feedback on thermobolts system
- Web guide
- E+L
- Rewinder description
- Rewinder for Jumbo reels and machine reels. Automaticreel change, reels extraction and new core position system. contact roller diam 495mm;
- Note
- Water termoregutation and pumping unit - Edge trim and in line re-feeding system into B extruder - Components : Drives : SIEMENS INVERTERS : SIEMENS Relais temporized : Weimuller Pneumatic components : CEMA Hydraulic components : Norgen Ball bearings : SKF Motors DC : SIEMENS Motors AC : Bima/SIEMENS Available several spare parts among which a spare die.
| Machine Code | CA142 |
| Manufacturer | TECHNO COATING ENGINEERING |
| Year | 2001 |
| Number of layers | 5 |
| Material | Stretch film LLDPE |
| Film width (mm) | 3000 |
| Extruder 1 Layer ref: | A |
| Screw diam 1 | 130 mm |
| Description 1 | L/D 30; Bimetallic barrel; Gravimetric doser; Motor 250Kw; hydraulic screen changer |
| Extruder 2 Layer ref: | B |
| Screw diam 2 | 160 mm |
| Description 2 | L/D 30; Bimetallic barrel; Gravimetric doserc; Motor 350Kw; 2x forced feeding for edge trim re-feeding system 130mm L/D6; hydraulic screen changer |
| Extruder 3 Layer ref: | C |
| Screw diam 3 | 160 mm |
| Description 3 | L/D 30; Bimetallic barrel; Gravimetric doser; Motor 350Kw; hydraulic screen changer |
| Extruder 4 Layer ref: | D |
| Screw diam 4 | 130 mm |
| Description 4 | L/D 30; Bimetallic barrel; Gravimetric doser; Motor 250Kw; hydraulic screen changer |
| Head description | Automatic die, Flex lip and thermobolt. Make EDI model: Autoflex 3700 m/m IV H40;Year 2010 . Die gap 0,1-1mm; Vacuum Box |
| Die width (mm) | 3700 |
| Chill roll unit | chill roll width 3800mm; firs chill roll diameter 980mm; Electrostati edge pinning system ELTEX; |
| Thickness controll system | Automatic. Make Electronic System model CTW-5000 ; double gauge thickness reading system with Beta rays, complete with control panel and feedback on thermobolts system |
| Web guide | E+L |
| Rewinder description | Rewinder for Jumbo reels and machine reels. Automaticreel change, reels extraction and new core position system. contact roller diam 495mm; |
| Note | Water termoregutation and pumping unit - Edge trim and in line re-feeding system into B extruder - Components : Drives : SIEMENS INVERTERS : SIEMENS Relais temporized : Weimuller Pneumatic components : CEMA Hydraulic components : Norgen Ball bearings : SKF Motors DC : SIEMENS Motors AC : Bima/SIEMENS Available several spare parts among which a spare die. |
