** SOLD **
In Flexo modular presses the printing units are put in line and are all built with separate frames.
Ask more informations
about a similar one
- Machine Code
- FM156
- Manufacturer
- BHS
- Modello
- FS 850- 10F
- Year
- 2014
- Number of colors
- 10
- Print possibilityes
- 10+0 , 9+1
- Overhaul/renovation
- Completely rebuilt by Gallus 2014 new motors , drives and controls in 2014 , PLC Siemens S7 , new UV system
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 860
- Print width (mm)
- 850
- Min print repeat (mm)
- 350
- Max print repeat (mm)
- 800
- Drying
- UV drying system by PRINTCONCEPT UV TECH for units 1- 10 -Additional Heated air drier with overhead tunnel for unit 10
- Unwinder type
- NON STOP
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- NON STOP
- Max reel diameter rewinder (mm)
- 1000
- Videocamera
- AVT
- Web guides
- yes in and out
- Anilox
- sleeves
- Note
- Speed: 250 m/min max Materials: Aluminium foil 20 to 90 my Laminates up to 250 gsm PET from 12 my OPP from 20 gsm Pulling calendar
| Machine Code | FM156 |
| Manufacturer | BHS |
| Modello | FS 850- 10F |
| Year | 2014 |
| Number of colors | 10 |
| Print possibilityes | 10+0 , 9+1 |
| Overhaul/renovation | Completely rebuilt by Gallus 2014 new motors , drives and controls in 2014 , PLC Siemens S7 , new UV system |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 860 |
| Print width (mm) | 850 |
| Min print repeat (mm) | 350 |
| Max print repeat (mm) | 800 |
| Drying | UV drying system by PRINTCONCEPT UV TECH for units 1- 10 -Additional Heated air drier with overhead tunnel for unit 10 |
| Unwinder type | NON STOP |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | NON STOP |
| Max reel diameter rewinder (mm) | 1000 |
| Videocamera | AVT |
| Web guides | yes in and out |
| Anilox | sleeves |
| Note | Speed: 250 m/min max Materials: Aluminium foil 20 to 90 my Laminates up to 250 gsm PET from 12 my OPP from 20 gsm Pulling calendar |
