ROTOMEC BOBST Rotopak 4000-2ES/1025/550/C Rotogravure printing machine 10 colors

Rotogravure printing machines (roto or gravure for short) perform a type of intaglio printing process, which involves engraving the image onto a cylinder which become the image carrier. Every printing job will require its dedicated set of engraved cylinders.

Machine Code	RO186
Manufacturer	ROTOMEC BOBST
Model	Rotopak 4000-2ES/1025/550/C
Year	2002
Number of colors	10
Print possibilities	10 col print, 9 col + coating/ cold seal; Print + Lamination in line; print units 1,8,9,10 reversible, unit 9 with 2 lamination units, possibility of cold seal in register on unit 10
Drive	Electronic shaft
Trolley system	Yes
Web width (mm)	1025
Print width (mm)	1000
Print repeat range (mm)	500-1000mm
Drying specifications	Pre treating unit 1,4m length, Unit 1 double hood 5m length 32 nozels 2 zones, unit2-7 single extended 3000mm 19 nozels, unit8 double extended hood 6000mm 38 nozels 2 zones, unit 9 double super extended 7000mm 46 nozels 2 zones, unit 10 double super extended 8000mm 52 nozels 2 zones
Drying heat surce	Thermal oil
Unwinder type	Turret two direction
Max reel diameter unwinder (mm)	1000
Rewinder type	Turret two direction
Max reel diameter rewinder (mm)	1000
Videocamera	Eltromat Camera + 100PCT inspectin AVT Apollo
Register control	Eltromat
Vyscosity control	Yes
Corona treatment	Albrandt
Print cylinders	No
Additional information	High performance rotogravure press. Mechanical Speed 550 m/min Secondary unwinder Turret max diam 1000mm Lamination unit AC driven. Roller water heated. Turning Bar Machine is currentlz dismantled
