Flexo CI presses use a central drum which is common to all colours as counter impression roll.
Ask more informations
- Machine Code
- FL1214
- Manufacturer
- UTECO
- Modello
- Onyx 808GL
- Year
- 2011
- Number of colors
- 8
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1230
- Print width (mm)
- 1200
- Min print repeat (mm)
- 360
- Max print repeat (mm)
- 800
- Unwinder type
- Turret automatic
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Double shaft electromagnetic brake, marriage rolls, dancing rollers
- Max reel diameter rewinder (mm)
- 800
- Drying
- Electric drying system
- Videocamera
- Grafikontrol
- Web guides
- Fife
- Vyscosity control
- Gama
- Inking system
- Closed chamber doctor blades
- Anilox
- 8 aniloxes
- Print Sleeves
- 490 sleeves
| Machine Code | FL1214 |
| Manufacturer | UTECO |
| Modello | Onyx 808GL |
| Year | 2011 |
| Number of colors | 8 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1230 |
| Print width (mm) | 1200 |
| Min print repeat (mm) | 360 |
| Max print repeat (mm) | 800 |
| Unwinder type | Turret automatic |
| Max reel diameter unwinder (mm) | 800 |
| Rewinder type | Double shaft electromagnetic brake, marriage rolls, dancing rollers |
| Max reel diameter rewinder (mm) | 800 |
| Drying | Electric drying system |
| Videocamera | Grafikontrol |
| Web guides | Fife |
| Vyscosity control | Gama |
| Inking system | Closed chamber doctor blades |
| Anilox | 8 aniloxes |
| Print Sleeves | 490 sleeves |
