Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".
Ask more informations
- Machine Code
- FL1085
- Manufacturer
- WINDMÖLLER & HÖLSCHER
- Modello
- PRIMAFLEX CL8
- Year
- 2010
- Number of colors
- 8
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1320
- Print width (mm)
- 1270
- Min print repeat (mm)
- 370
- Max print repeat (mm)
- 1070
- Unwinder type
- Turret non stop
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Turret non stop
- Max reel diameter rewinder (mm)
- 1000
- Drying
- Gas drying. 2 Burners 4 fans. Automatic air recirculation system with ENPRO LEL system
- Videocamera
- BST ELTROMAT Year 2022, model IPQ 100% inspection
- Vyscosity control
- Yes automatic Ink Spec
- Washing system
- Automatic Washing system Turbo clean
- Inking system
- Closed chamber doctor blades
- Anilox
- 8
- Print Sleeves
- 8
- Note
- mechanical speed 400m/min Easy set: automatic print pressure setting Easy reg: automatic register setting
| Machine Code | FL1085 |
| Manufacturer | WINDMÖLLER & HÖLSCHER |
| Modello | PRIMAFLEX CL8 |
| Year | 2010 |
| Number of colors | 8 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1320 |
| Print width (mm) | 1270 |
| Min print repeat (mm) | 370 |
| Max print repeat (mm) | 1070 |
| Unwinder type | Turret non stop |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | Turret non stop |
| Max reel diameter rewinder (mm) | 1000 |
| Drying | Gas drying. 2 Burners 4 fans. Automatic air recirculation system with ENPRO LEL system |
| Videocamera | BST ELTROMAT Year 2022, model IPQ 100% inspection |
| Vyscosity control | Yes automatic Ink Spec |
| Washing system | Automatic Washing system Turbo clean |
| Inking system | Closed chamber doctor blades |
| Anilox | 8 |
| Print Sleeves | 8 |
| Note | mechanical speed 400m/min Easy set: automatic print pressure setting Easy reg: automatic register setting |
