** SOLD **
Flexographic printing machines (often abbreviated as flexo press) perform a printing process which utilizes a flexible relief plate to transfer ink to printed substrate. Every printing job will require its dedicated set of plates.
Ask more informations
about a similar one
- Machine Code
- FL943
- Manufacturer
- COMEXI
- Modello
- FP 2108 CNC GL
- Year
- 2003
- Number of colors
- 8
- Print possibilityes
- 8+0
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1270
- Print width (mm)
- 1220
- Min print repeat (mm)
- 350
- Max print repeat (mm)
- 700
- Unwinder type
- Shaftless Turret
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Shaftless turret
- Max reel diameter rewinder (mm)
- 1000
- Drying
- 2 zones , 4 fans , 55 mt tunnel, electric heaters
- Videocamera
- AVT Prelude
- Corona treatment
- Yes AFS
- Web guides
- Yes BST OPG before print section and before rewinder
- Vyscosity control
- Yes INELME
- Washing system
- Yes included
- Inking system
- Closed chamber doctor blades
- Anilox
- 20 ceramic anilox sleeves
- Print Sleeves
- 350 print sleeves
- Note
- Re print system Chiler thermo regulation for CI drum
Machine Code | FL943 |
Manufacturer | COMEXI |
Modello | FP 2108 CNC GL |
Year | 2003 |
Number of colors | 8 |
Print possibilityes | 8+0 |
Gearless | Yes |
Fast sleeve change | Yes |
4 motor per deck CNC position system | Yes |
Computer supervision | Yes |
Web width (mm) | 1270 |
Print width (mm) | 1220 |
Min print repeat (mm) | 350 |
Max print repeat (mm) | 700 |
Unwinder type | Shaftless Turret |
Max reel diameter unwinder (mm) | 1000 |
Rewinder type | Shaftless turret |
Max reel diameter rewinder (mm) | 1000 |
Drying | 2 zones , 4 fans , 55 mt tunnel, electric heaters |
Videocamera | AVT Prelude |
Corona treatment | Yes AFS |
Web guides | Yes BST OPG before print section and before rewinder |
Vyscosity control | Yes INELME |
Washing system | Yes included |
Inking system | Closed chamber doctor blades |
Anilox | 20 ceramic anilox sleeves |
Print Sleeves | 350 print sleeves |
Note | Re print system Chiler thermo regulation for CI drum |
